Amphenol Communications Solutions Bergstik Series Straight Through Hole Pin Header, 6 Contacts, 2.54 mm 77311-101-06LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1.5kV |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 3A |
| Model | 77311-101-06LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CHINA RoHS, EU RoHS, REACH/SvHC |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 2.41mm |
| Mating Pin Length | 5.84mm |
Key Features
- Designed for board-to-board and wire-to-board applications.
- Features a straight orientation with unshrouded male contacts.
- Constructed with high temperature thermoplastic housing compatible with reflow soldering.
- Contact material is phosphor bronze with cost-effective duplex gold plating.
- Operates reliably from -65°C to 125°C.
- Pin headers can be cut to length to fit application needs.
- Includes stand-offs to allow solder contamination removal during assembly.
- Compatible with multiple mating connectors such as Dubox, Quickie IDC, and PV series crimps.
Product Description
Amphenol Communications Solutions 77311-101-06LF Bergstik Series Straight Through Hole Pin Header provides a reliable electrical connection solution for industrial and electronic applications. This pin header features 6 gold-plated male contacts arranged in a single row with a 2.54 mm pitch, ideal for both board-to-board and wire-to-board interfaces.
The housing is made from reflow solder compatible high temperature thermoplastic with UL 94 V-0 flammability rating, ensuring durability and stability under demanding operating environments ranging from -65°C to 125°C. The phosphor bronze contacts have cost-effective duplex gold plating enhancing corrosion resistance and conductivity.
These pin headers can be customized by cutting to exact lengths required for the application. Stand-offs on the housing allow for effective solder contamination removal during manufacturing processes. The tail pin length is 2.41 mm and the mating pin length is 5.84 mm, providing secure mechanical and electrical engagement.
This product complies with environmental standards including CHINA RoHS, EU RoHS, and REACH/SvHC, ensuring it meets strict regulatory requirements for hazardous substances. Typical applications include industrial electronics assemblies, communication equipment, instrumentation, and consumer electronics.
Designed for board-to-board and wire-to-board applications. High temperature thermoplastic housing with UL 94 V-0 rating. Phosphor bronze contacts with duplex gold plating for optimal conductivity. Operates reliably in temperatures from -65°C to 125°C.
Rated voltage of 1.5 kV and current of 3 A. Customizable length by cut-to-size capability. Stand-offs facilitate solder contamination removal. Compatible with a wide range of mating connectors. RoHS and REACH compliant, environmentally safe.
This pin header is an economical and versatile solution suitable for use in industrial, electronic manufacturing, communication systems, and PCB board development environments. Browse more PCB Headers and connectors at EnvMart for comprehensive electronics component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this pin header is 1.5 kV.
This model has a current capacity of 3 A.
It operates reliably within a temperature range of -65°C to 125°C.
The housing is made from high temperature thermoplastic, and the contacts are made of phosphor bronze with duplex gold plating.
This pin header features 6 male contacts.
The pitch of the contacts is 2.54 mm.
Yes, this model is designed for through hole mounting.
The tail pin length is 2.41 mm, and the mating pin length is 5.84 mm.
It complies with CHINA RoHS, EU RoHS, and REACH/SvHC standards.
Yes, it can be cut to the exact lengths required for specific applications.
Typical applications include industrial electronics assemblies, communication equipment, instrumentation, and consumer electronics.
The termination type for this model is solder.
