Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header 5 Contacts 4.2 mm Pitch 1 Row Shrouded 39-30-3056

Molex 39-30-3056 Mini-Fit Jr Series Right Angle Through Hole PCB Header is engineered for robust and reliable power interconnections in electronics applications. This PCB header includes 5 male contacts arranged in a single row with a precise 4.2 mm pitch, facilitating high current wiring needs up to 12A per circuit. The shrouded nylon housing protects terminals from debris and mechanical damage while scooping-proof design ensures pin safety during mating.

The connector system is designed for wire-to-board applications featuring a right-angle orientation that optimizes PCB layout space. Brass contacts with tin plating provide excellent electrical conductivity and protection against corrosion, essential for industrial, commercial, and communication equipment requiring dependable power delivery. Operating temperature ranges from -40°C to 105°C accommodate diverse environmental conditions.

This PCB header boasts enhanced safety and usability features including polarization, keying, and a positive locking mechanism which provides tactile and audible feedback to confirm full mating and prevent accidental disconnection due to vibration or shock. Mounting is via through-hole with solder termination ensuring a secure and stable PCB installation.

Applications for the Mini-Fit Jr series connectors include industrial automation equipment, rack-mount servers, office equipment, consumer white goods, and networking hardware. The product is manufactured in Mexico ensuring high-quality benchmarks.

Designed for up to 12A current per circuit ensuring high performance. Features a shrouded housing made of durable nylon material. Right angle orientation with one row of contacts for reliable wire-to-board connection. Constructed with brass contacts plated with tin for improved conductivity and corrosion resistance.

Operates between -40°C to 105°C temperature range. Provides a 600V voltage rating for demanding electrical environments. Incorporates polarization and keying to prevent misalignment and mismating. Includes a positive locking mechanism with audible click for secure connection.

Through hole mount type suitable for PCB installation with solder termination. Explore more technical products in the PCB Headers category at EnvMart for quality connectors and reliable electronic components.
