Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header, 16 Contacts, 4.2 mm Pitch, 2 Row, Shrouded 39-29-1167
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 6A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Fit Jr |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Supports up to 6A current per contact for robust power delivery.
- Manufactured with a durable Nylon housing that is shrouded for protection.
- Features tin-plated brass contacts for reliable electrical conductivity.
- Designed with scoop-proof housing to prevent contact damage during mating.
- Includes positive locking mechanism with audible click for secure mating confirmation.
- Operates within a temperature range of -40°C to 105°C for industrial environments.
- Connector orientation is right angle with through hole mount type for stable PCB attachment.
- Polarization and keying features prevent mismating with receptacles.
Product Description
Molex 39-29-1167 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a high-quality connector designed for wire-to-board applications. This shrouded male header has 16 contacts arranged in 2 rows with a 4.2 mm pitch, ensuring secure connections and high current handling capability of up to 6 amperes per circuit. The Nylon housing provides robustness and protects the terminals from damage.
The connector features fully isolated terminals and scoop-proof housing design that prevents damage to contacts during mating at severe angles. Its positive locking mechanism ensures the connector remains firmly engaged and produces an audible click to confirm proper mating. Polarization and keying features reduce the risk of mismating, enhancing reliability in critical industrial applications.
This PCB header is rated for a maximum operating temperature of 105°C and a voltage rating of 600V, making it suitable for demanding environments including consumer white goods, industrial automation, servers, routers, and office equipment.
The connector utilizes tin-plated brass contacts with solder termination type, ensuring consistent electrical performance and ease of PCB assembly. Its right angle orientation with through hole mounting offers durable mechanical retention during operational vibration or shock.
Molex Mini-Fit Jr connectors offer design flexibility for high density and high current applications, providing secure and reliable interconnections in industrial, commercial, and electronic equipment manufacturing.
Supports up to 6A current per contact. Durable Nylon shrouded housing protects contacts. Tin-plated brass male contacts ensure conductivity. Scoop-proof housings prevent terminal damage during mating. Positive locking mechanism with audible click confirms mating.
Operating temperature range: -40°C to 105°C. Right angle orientation with through hole mount. Polarization and keying prevent mismating. Voltage rating up to 600V. Ideal for industrial automation, networking, and office equipment.
Explore Molex Mini-Fit Jr Series and other PCB connector solutions at EnvMart for reliable electronic component sourcing and industrial application needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum current of 6A per contact, making it suitable for robust power delivery applications.
The voltage rating for this model is 600V, allowing it to be used in high-voltage applications.
The contacts in this connector are arranged with a pitch of 4.2 mm, ensuring secure connections.
The housing is made from durable Nylon, and the contacts are made of tin-plated brass, ensuring reliable electrical conductivity.
It operates within a temperature range of -40°C to 105°C, making it suitable for industrial environments.
This model features 16 contacts arranged in 2 rows, providing ample connection points for applications.
This connector uses a through hole mount type, ensuring stable attachment to the PCB.
Yes, it includes polarization and keying features that help prevent mismating with receptacles, enhancing reliability.
The orientation of this connector is right angle, allowing for efficient space utilization on the PCB.
It utilizes a solder termination type, facilitating easy PCB assembly and reliable connections.
It features a positive locking mechanism that provides an audible click to confirm secure mating, ensuring connection integrity.
The country of origin for this PCB header is China.
