Molex KK 396 Series 7-Contact Straight Through Hole Pin Header 3.96 mm Pitch 1 Row Unshrouded 09-65-2078
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.6mm |
Key Features
- Constructed with brass contacts and tin plating for durable conductivity.
- Utilizes nylon housing material to ensure insulation and mechanical strength.
- Designed for through-hole mounting with straight orientation for PCB integration.
- Operates safely from -40°C up to 105°C temperature range.
- Rated for 7A current and 250V operating voltage for robust electronic applications.
- Tail pin length of 3.6 mm facilitates secure soldering.
- Compatible with KK 396 series crimp housings with friction locking for secure mating.
Product Description
Molex 09-65-2078 KK 396 Series Straight Through Hole Pin Header is a reliable 7-contact pin header designed for wire-to-board electrical connections with a 3.96 mm pitch and 1 row configuration. It features brass contacts with tin plating housed in nylon for optimal electrical insulation and mechanical strength.
This PCB connector is intended for through-hole mounting with a straight orientation and unshrouded design, making it suitable for various electronic assemblies. It supports operating currents up to 7A and voltages up to 250V, and can function reliably in temperature ranges from -40°C to 105°C, accommodating diverse industrial environments.
The contact tail pins are 3.6 mm in length to ensure secure solder joint formation. This pin header series is compatible with KK 396 and SPOX crimp housings featuring friction locking mechanisms for stable, vibration-resistant connections.
These pin headers find extensive use in automotive, industrial, consumer electronics, datacommunications, and telecommunications applications where robust, dependable PCB connector solutions are required.
Constructed with brass contacts and tin plating for durable conductivity. Utilizes nylon housing material to ensure insulation and mechanical strength. Designed for through-hole mounting with straight orientation for PCB integration.
Operates safely from -40°C up to 105°C temperature range. Rated for 7A current and 250V operating voltage for robust electronic applications. Tail pin length of 3.6 mm facilitates secure soldering. Compatible with KK 396 series crimp housings with friction locking for secure mating.
Browse EnvMart's extensive PCB Pin Header category for high-quality connectors from renowned manufacturers like Molex.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 7A, making it suitable for robust electronic applications.
It operates at a maximum voltage of 250V, allowing for a wide range of electronic applications.
The pitch of this model is 3.96 mm, which is standard for various PCB applications.
It features brass contacts with tin plating for conductivity and a nylon housing for insulation and mechanical strength.
The tail pin length is 3.6 mm, facilitating secure soldering during installation.
This model can operate safely within a temperature range of -40°C to 105°C, accommodating diverse industrial environments.
Yes, it is designed for through-hole mounting with a straight orientation, suitable for PCB integration.
It utilizes a wire-to-board connector system, making it suitable for various electronic assemblies.
This model features 7 contacts, allowing for multiple connections in a single header.
The orientation of this model is straight, which is standard for many PCB applications.
Yes, it is compatible with KK 396 and SPOX crimp housings that feature friction locking for secure mating.
The contacts in this model are male, designed for secure connections with female counterparts.
