Molex Micro-Fit 3.0 Series Straight Through Hole PCB Socket 6-Contact 1 Row 3 mm Pitch Solder 43650-0629

Free Delivery in India | Lowest Global Shipping Charges

Molex Micro-Fit 3.0 Series Straight Through Hole PCB Socket 6-Contact 1 Row 3 mm Pitch Solder 43650-0629

Name: Molex Micro-Fit 3.0 Series Straight Through Hole PCB Socket 6-Contact 1 Row 3 mm Pitch Solder 43650-0629
Brand: Molex
SKU: 206991
Price: 2.67 USD
Availability: InStock



Category Electronics Components Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Straight
Current	12A
Mount Type	Through Hole
Housing Material	Thermoplastic
Contact Material	Brass
Series	Micro-Fit 3.0
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Wire-to-Board
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	3mm
Contact Plating	Brass
Number of Contacts	6
Contact Gender	Male
Connector System	Power, Wire-to-Board

Key Features

This power connector system supports up to 12A current capacity at 250V.
Housing made from high-temperature thermoplastic material ensures durability.
Positive latching mechanism provides secure mating and prevents accidental disconnection.
Designed for through hole mounting with SMT compatibility for manufacturing efficiency.
Suitable for use in military, solar power, consumer appliances, medical, telecommunications, and gaming terminals.

Product Description

Molex 43650-0629 Micro-Fit 3.0 Series Straight Through Hole PCB Socket features a 6-contact, single row design with 3 mm pitch solder termination, providing a compact and reliable wire-to-board power connection solution.

Constructed with a thermoplastic housing, this connector supports operating voltages up to 250V and can carry a current of 12A, making it suitable for a wide range of low to mid power applications. The male contact gender connector integrates positive latching with a locking ramp to secure connections and prevent accidental disconnections during operation.

The series is designed to withstand minimum operating temperatures of -40°C and maximum temperatures of up to 125°C, suitable for demanding environments. Contacts are made of brass with brass plating to ensure excellent conductive properties and durability.

Featuring through hole mounting with SMT compatibility, the connector aids efficient assembly while the PCB polarizing pegs assist in accurate positioning and alignment on the circuit board. The fully isolated dual beam terminals reduce arcing and enhance electrical performance.

This Micro-Fit 3.0 connector series is ideal for industrial use cases such as military commercial off-the-shelf (COTS) equipment, solar power installations, household consumer products including dryers and refrigerators, data communications equipment like routers and servers, medical devices, telecommunications infrastructure, and gaming terminals.

Supports high current carrying capacity of 12A in a compact footprint. Housing material is thermoplastic rated for high temperature reflow soldering. Positive latching ensures secure, reliable mating connection. Through hole mount type compatible with SMT processes.

Pcb polarizing pegs and kinked solder legs provide alignment and retention. Explore more related products in the PCB Sockets category here on EnvMart.
