Molex KK 508 Series Straight Through Hole Pin Header 8 Contacts 5.08 mm Pitch 1 Row Unshrouded 10-08-5081

Free Delivery in India | Lowest Global Shipping Charges

Molex KK 508 Series Straight Through Hole Pin Header 8 Contacts 5.08 mm Pitch 1 Row Unshrouded 10-08-5081

Name: Molex KK 508 Series Straight Through Hole Pin Header 8 Contacts 5.08 mm Pitch 1 Row Unshrouded 10-08-5081
Brand: Molex
SKU: 206394
Price: 1.63 USD
Availability: InStock



Category Electronics Components Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Straight
Current	7A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	KK 508
Termination Type	Solder
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	5.08mm
Contact Plating	Tin
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	3.94mm

Key Features

The connector features 8 brass contacts plated with tin for reliable conductivity.
Mount type is through hole with a tail pin length of 3.94 mm for secure soldering.
Housing is made from durable nylon material ensuring insulation and mechanical stability.
Designed for operating voltage up to 250 V and current rating of 7 A.
Operating temperature range from minus 40 degrees Celsius up to 80 degrees Celsius.
This unshrouded male contact header is oriented straight and offers a 5.08 mm row pitch.
Compatible with Molex 2599 series polarizing backwall headers and mates with housings in 3001 and 5058 series.
The KK 508 Series provides economical, reliable interconnection for wire-to-board applications.

Product Description

Molex 10-08-5081 KK 508 Series Straight Through Hole Pin Header is a high-quality wire-to-board connector featuring 8 brass contacts with tin plating, housed in a durable nylon body designed for lasting performance. With a pitch of 5.08 mm and a single row configuration, this unshrouded male contact header is ideal for various industrial and electronic assembly applications.

The termination type is solder, with a tail pin length of 3.94 mm, allowing efficient and reliable PCB mounting. It supports a maximum voltage of 250 V and a current rating of 7 A, operating reliably across temperatures from -40°C to 80°C.

This connector is designed to mate seamlessly with Molex 2599 Series polarizing backwall headers as well as 3001 and 5058 Series housings, providing a standardized and economical solution for wire-to-board and board-to-board interconnections.

Constructed with a nylon housing and brass contacts, plated with tin, the KK 508 Series ensures excellent mechanical strength and electrical conductivity. It is straight-oriented and unshrouded, making it suitable for applications where space and ease of assembly are considerations.

The connector has 8 contact points for secure connectivity. It uses a 5.08 mm pitch between contacts suitable for industrial standards. The housing material is nylon, providing excellent durability. It can handle 7 A current and 250 V voltage for various electronic devices.

Designed for through-hole mounting with solder termination. Contact gender is male, and the pin length is 3.94 mm for secure joining. Temperature range supports demanding environments from -40°C to 80°C. This product is new and unshrouded for flexibility in design.

This Molex KK 508 Series Pin Header is ideal for use in electronic manufacturing, board assembly, and industrial connector applications where a reliable, standardized, and cost-effective solution is critical.
