Molex Milli-Grid Female Connector Housing 2 mm Pitch 12 Way 2 Row Straight 51110-1250
Specifications
| Country of Origin | India |
|---|---|
| Brand | Molex |
| Orientation | Straight |
| Length | 12.2mm |
| Width | 4.8mm |
| Mount Type | Cable |
| Housing Material | Polyethylene Terephthalate |
| Series | Milli-Grid |
| Number of Rows | 2 |
| Pitch | 2mm |
| For Use With | Milli-Grid Connector |
| Number of Contacts | 12 |
| Connector Gender | Female |
Key Features
- The 2.00 mm Milli-Grid grid pattern offers high density for compact electronic designs.
- The shrouded design protects contacts from damage ensuring durability.
- Equipped with a centre polarization key to prevent mismating.
- Suitable for various wire to board signal applications in printers and automotive systems.
- Constructed from polyethylene terephthalate for robust housing material.
- Feature straight orientation with cable mount type for direct cable connections.
- Provides a secure connection with options for center locking ramps and side latches in related parts.
- Compact dimensions of 12.2 mm length and 4.8 mm width make it suitable for dense PCB layouts.
Product Description
Molex 51110-1250 is a high-performance female connector housing from the Milli-Grid series, featuring a 2 mm pitch and 12 way, 2 row straight configuration. This connector housing is fabricated using durable polyethylene terephthalate material, ensuring excellent mechanical stability and contact protection.
The precise 2.00 x 2.00 mm grid pattern provides a high density layout, facilitating efficient use of PCB space while maintaining signal integrity. The shrouded design safeguards the receptacle crimp contacts against potential damage, enhancing longevity.
A centre polarization key is incorporated to prevent mismating by aligning with mating headers, and additional features including centre locking ramps and side latches in related connector variants provide secure mating connections.
This female connector housing is optimized for cable mounting with a straight orientation, making it well-suited for reliable wire-to-board interconnect applications.
Typical industrial, commercial, and electronic applications include use in printers, fax machines, copiers, automotive audio systems, GPS devices, security alarms, routers, switches, set-top boxes, and digital media players.
The Milli-Grid connector system from Molex offers versatile options including shrouded and unshrouded headers, dual-row receptacles, connector housings, and crimp terminals, supporting various interconnection requirements in electronics manufacturing.
The 2.00 mm grid design enables high-density connector layouts for tight PCB spaces. Shrouded contacts provide robust protection and longevity under regular use. Centre polarization keys prevent incorrect mating and ensure proper assembly.
Cable mount type with straight orientation allows easy wire-to-board integration. Housing material polyethylene terephthalate provides mechanical strength and chemical resistance. Widely used across industrial, automotive, and consumer electronic sectors.
Compact dimensions accommodate modern miniaturized electronic devices. Reliable performance in signal transmission applications. Explore Molex Connector Housings and accessories on EnvMart for precision components to enhance your electronic assembly projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the Molex Milli-Grid Female Connector Housing is 2 mm.
This model supports 12 contacts in a 2-row configuration.
The connector housing features a straight orientation for cable mounting.
The housing is constructed from polyethylene terephthalate, providing mechanical strength and chemical resistance.
The dimensions of the housing are 12.2 mm in length and 4.8 mm in width.
It is suitable for various wire-to-board signal applications in printers, automotive systems, and other electronic devices.
This housing is designed for use with the Milli-Grid Connector series, ensuring compatibility with related connectors.
Yes, it includes a centre polarization key to prevent mismating with mating headers.
The connector housing uses a cable mount type for direct cable connections.
The country of origin for this connector housing is India.
This connector housing belongs to the Milli-Grid series from Molex.
Related connectors may include features such as centre locking ramps and side latches for secure mating connections.
