Texas Instruments I2C Translator Voltage Level Translator 2 Voltage Level 8-Pin SSOP PCA9306DCTR

Texas Instruments PCA9306DCTR is a high-performance I2C voltage level translator designed to enable smooth voltage-level transitions in communication systems operating at different logic levels. The device features a bi-directional function supporting the I2C logic family and is packaged in an 8-pin SSOP surface mount format, offering compactness with a height of 1.3 millimeters and length of 4.25 millimeters.

Operating over a wide temperature range from -40°C to 85°C, the PCA9306DCTR ensures reliability under diverse environmental conditions. It supports a maximum supply voltage of 5 volts with a minimum supply voltage down to 0 millivolts, facilitating flexible integration into various electronic designs. The device includes two voltage-level translators per chip with a very low maximum propagation delay time of 1.5 nanoseconds, facilitating high-speed signal translations for I²C and SMBus applications.

This component features a maximum high-level output current of 128 milliamperes and a three-state output type, supporting versatile circuit configurations. It is designed for surface mounting, which aids efficient automated assembly and compact circuit layouts.

Bi-directional voltage level translator ideal for interfacing devices operating at different logic voltages. Compact 8-pin SSOP surface mount package suitable for space-constrained applications. Wide operating temperature range from -40°C to 85°C for industrial-grade applications.

Low propagation delay of 1.5 nanoseconds ensures minimal latency in signal translation. Supports I2C and SMBus protocols, enabling broad compatibility with communication buses. Maximum supply voltage of 5V and output current rating of 128mA for robust electrical performance.

Two elements per chip provide efficient dual translator functionality.

Commonly used in industrial electronics, communication interface circuits, and embedded systems requiring seamless voltage level shifting for I²C bus compatibility. This device contributes to signal integrity and system stability in mixed-voltage environments.
