ROHM 100 V 1 A Schottky Barrier Diode Surface Mount SOD-123FL RB168MM100TR

Free Delivery in India | Lowest Global Shipping Charges

ROHM 100 V 1 A Schottky Barrier Diode Surface Mount SOD-123FL RB168MM100TR

Name: ROHM 100 V 1 A Schottky Barrier Diode Surface Mount SOD-123FL RB168MM100TR
Brand: ROHM
SKU: 201494
Price: 0.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	0.8mm
Length	2.6mm
Model	RB168MM100TR
Width	1.6mm
Mount Type	Surface
Series	RB168MM100
Maximum Operating Temperature	150°C
Package Type	SOD-123FL
Minimum Operating Temperature	55°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	100V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	400mA
Peak Non-Repetitive Forward Surge Current Ifsm	40A
Maximum Forward Voltage Vf	810mV
Peak Reverse Recovery Time trr	7.2ns

Key Features

Surface mount diode designed for high efficiency rectification applications.
Maximum continuous forward current of 1 ampere for reliable operation.
Peak reverse repetitive voltage rating of 100 volts ensuring robust performance.
Low forward voltage drop of 810 millivolts improves energy efficiency.
Short peak reverse recovery time of 7.2 nanoseconds for fast switching.
Compact dimensions of 2.6 mm length, 1.6 mm width, and 0.8 mm height for space-saving PCB layouts.
Automotive grade AEC-Q101 certification ensuring high reliability under harsh conditions.
Wide operating temperature range from -55°C to 150°C suitable for industrial environments.

Product Description

ROHM RB168MM100TR Schottky Barrier Diode is a high-performance semiconductor device designed for efficient rectification in power supply and switching applications. This diode features a surface-mount SOD-123FL package with compact dimensions of 2.6 mm length, 1.6 mm width, and 0.8 mm height, enabling its use in space-constrained electronic designs.

It offers a maximum continuous forward current of 1 ampere and peak reverse repetitive voltage of 100 volts, suitable for low voltage power conversion and protection circuits. The diode's low forward voltage drop of 810 millivolts reduces power loss, enhancing overall circuit efficiency. With a peak reverse recovery time of 7.2 nanoseconds, it supports fast switching, making it ideal for high frequency applications.

The device complies with the automotive AEC-Q101 standard, underscoring its durability and reliability in harsh industrial and automotive environments. Its operating temperature range from -55°C to 150°C further enables its use in demanding conditions, including industrial machinery, HVAC control systems, and automotive electronics.

Featuring a single diode configuration with two pins, the RB168MM100TR simplifies circuit integration while the peak non-repetitive forward surge current rating of 40 amperes offers resilience to transient surges commonly encountered in industrial power systems.

Surface mount design for automated assembly processes and compact PCBs. High current and voltage ratings tailored for power supply and switching use cases. Automotive qualification ensures reliability for automotive and industrial sectors.

Compact size supports modern electronics with limited space availability. Robust temperature tolerance suitable for a variety of industrial applications.

The ROHM RB168MM100TR Schottky Barrier Diode is ideal for engineers and technicians designing electronic circuits requiring efficient, fast, and reliable diode components. Its widespread applications include industrial automation systems, power management modules, consumer electronics, and automotive electronic systems.

Explore EnvMart's Semiconductor category for a comprehensive range of diodes and related electronic components credible for your industrial and laboratory requirements.
