onsemi Zener Diode 16 V, 500 mW, 5% Tolerance, Surface Mount 2-Pin SOD-123 Package MMSZ16T1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Zener Diode 16 V, 500 mW, 5% Tolerance, Surface Mount 2-Pin SOD-123 Package MMSZ16T1G

Name: onsemi Zener Diode 16 V, 500 mW, 5% Tolerance, Surface Mount 2-Pin SOD-123 Package MMSZ16T1G
Brand: onsemi
SKU: 200494
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	3.86mm
Model	MMSZ16T1G
Mount Type	Surface
Series	MMSZxxxT1G
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	16V
Zener Type	Voltage Regulator
Maximum Zener Impedance	40Ω
Surface Mount case	SOD-123

Key Features

Single diode configuration with 2 pins for compact mounting.
Nominal Zener voltage of 16 volts with 5% tolerance.
Maximum power dissipation rating of 500 mW ensuring reliable operation.
Surface mount type suitable for automated PCB assembly.
Test current specified at 5 mA for accurate regulation.
Maximum impedance of 40 ohms enhances voltage stability.
Maximum reverse leakage current is only 50 nA, minimizing power loss.
Operational temperature range from -55°C to 150°C for harsh environments.

Product Description

onsemi MMSZ16T1G Zener Diode is a high-reliability semiconductor device designed for voltage regulation and protection applications in electronics. It features a nominal Zener voltage of 16 V and can dissipate up to 500 mW power within a compact surface-mount package (SOD-123).

This diode is configured as a single element with two pins that enable secure surface mounting on printed circuit boards, making it ideal for automated manufacturing processes. Its electrical characteristics include a test current of 5 mA and a maximum Zener impedance of 40 Ω, delivering precise voltage regulation and low noise performance.

The maximum reverse leakage current is limited to 50 nA ensuring minimal power loss and high efficiency in power-sensitive circuits. This device is suitable for operating under a wide temperature range from -55°C to 150°C, supporting demanding industrial, automotive, and commercial electronics environments.

The compact physical dimensions (length 3.86 mm and height 1.35 mm) make it a space-saving solution for modern electronics requiring stable voltage reference. This Zener diode belongs to the MMSZxxxT1G series from onsemi, recognized for quality and durability in discrete semiconductor components.

Single diode configuration with 2-pin surface mount design. Nominal 16 V Zener voltage and 5% tolerance rating. Maximum power dissipation of 500 mW for reliable performance. Low leakage current and controlled impedance for improved stability.

Wide operating temperature range from -55°C to 150°C. Compact SOD-123 surface mount package for PCB integration. Suitable for industrial, automotive, and commercial electronics applications. Test current of 5 mA ensures accurate voltage regulation.

Ideal for voltage regulation and protection within power supply circuits. Manufactured to high quality and performance standards by onsemi.

This Zener diode is a versatile component widely used in electronic circuits requiring voltage stabilization and transient suppression. It supports various industrial sectors including power electronics, telecommunications, automotive electronics, and consumer devices. For further components and technical specifications, EnvMart offers an extensive selection of onsemi products and related semiconductor devices.
