Panasonic ECHU(X) Surface Mount Film Capacitor 2.7nF 50V dc 50V ac PPS 125°C ECHU1H272GX5

Panasonic ECHU1H272GX5 surface mount film capacitor is a high-performance PPS film capacitor rated at 50V dc and 50V ac with 2.7nF capacitance, designed for PCB assembly and compact electronic circuits.

These film capacitors are constructed from stacked metallised PPS film without moulding, offering outstanding temperature tolerance up to 125°C and excellent electrical characteristics such as low Equivalent Series Resistance (ESR).

The capacitor is robust against operating conditions of 85°C and 85% relative humidity for 500 hours, making it suitable for industrial electronic applications and commercial manufacturing processes.

Its compact design with a length of 2mm, width 1.25mm, and height 0.9mm enables efficient use of PCB real estate. Panasonic ECHU(X) capacitors are engineered for reflow soldering only, providing reliable solder joint integrity in automated assembly lines.

Typical applications include time-constant circuits, oscillators, resonance circuits, filters, and audio electronics where signal fidelity is critical. Compact PPS film chip capacitor with mould-less design and low ESR. Rated for 50V dc, 50V ac operation at up to 125°C maximum temperature.

Compliant with RoHS directives, ensuring environmentally friendly manufacturing. Small surface mount package size optimizes PCB footprint. Excellent suitability for reflow soldering in mass production. Durability tested to 85°C / 85% RH for 500 hours under voltage stress.

Ideal for industrial, electronic component manufacturing, and commercial circuit uses.

This Panasonic film capacitor is part of the ECHU(X) series, known for precision and durability in passive electronic components. Discover a wide selection of Film Capacitors and other electronic components available at EnvMart to meet sophisticated industrial and manufacturing needs.
