Wurth Elektronik WE-PD2 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 1μH ±20% 4A 110MHz 7447730
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 3.2mm |
| Length | 4.5mm |
| Model | 7447730 |
| Depth | 4mm |
| Packaging | Tape & Reel |
| Series | WE-PD2 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 4A |
| Maximum DC Resistance | 49mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Tin/Copper |
| Maximum Self Resonant Frequency | 110MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact surface mount package measuring 4.5mm x 3.2mm x 4mm.
- Features a wirewound inductor construction on a ferrite core.
- Maximum DC resistance is 49mΩ ensuring efficient performance.
- Operates over temperature range from -40°C to 125°C.
- Maximum self-resonant frequency of 110MHz for high-frequency applications.
- Termination style uses tin/copper for reliable soldering.
- Complies with RoHS standards and automotive AEC-Q200 certification.
- Sold in tape & reel packaging suitable for high volume assembly.
Product Description
Wurth Elektronik 7447730 WE-PD2 series unshielded wirewound surface mount inductor features a ferrite core and delivers an inductance of 1μH with ±20% tolerance. It supports a maximum DC current of 4A, suitable for demanding electronic circuits requiring high current handling in compact form factors.
The component measures 4.5mm in length, 3.2mm in height, and 4mm in depth, designed with a wirewound construction ideal for improved magnetic and electrical performance. The inductor's maximum DC resistance of 49mΩ ensures minimal power loss, contributing to enhanced circuit efficiency.
Operating temperature ranges from -40°C to 125°C, making it suitable for industrial, automotive, and consumer electronics applications. The inductor has a maximum self-resonant frequency of 110MHz, enabling usage in switching regulators, DC/DC converters, and other high-frequency power circuits.
The WE-PD2 series is recommended for reflow soldering and delivered in tape & reel packaging facilitating automated assembly processes. Its tin/copper termination style guarantees robust solder joint integrity.
These inductors comply with RoHS environmental standards and meet automotive AEC-Q200 requirements, ensuring reliability and safety in automotive electronics.
Application areas for the 7447730 include switching regulators with low operating voltages used in computers, laptops, mobile phones, and pagers, as well as integrated DC/DC converters requiring high efficiency.
Discover the Wurth Elektronik product range and other related Surface Mount Inductors at EnvMart for industrial electronics production needs. Compact surface mount format ensures space-saving on PCBs. High current rating supports demanding power electronics.
Ferrite core improves energy storage and magnetic performance. Wirewound construction optimizes inductance stability and tolerance. Suitable for automotive and industrial electronic equipment.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductor has an inductance value of 1μH with a tolerance of ±20%.
It supports a maximum DC current of 4A, making it suitable for high current applications.
The dimensions of this inductor are 4.5mm in length, 3.2mm in height, and 4mm in depth.
The maximum self-resonant frequency is 110MHz, allowing for use in high-frequency applications.
It operates over a temperature range from -40°C to 125°C, suitable for various environments.
This model features a wirewound construction on a ferrite core, optimizing its performance.
The maximum DC resistance is 49mΩ, which helps in minimizing power loss.
It uses a tin/copper termination style, ensuring reliable soldering.
Yes, it complies with RoHS standards and meets automotive AEC-Q200 certification.
It is sold in tape & reel packaging, which is suitable for high volume assembly.
This inductor is suitable for applications such as switching regulators and integrated DC/DC converters.
The country of origin for this inductor is India.
