Broadcom DC Input Optocoupler Through Hole 8-Pin DIP HCPL-2300-000E
Specifications
| Country of Origin | India |
|---|---|
| Brand | Broadcom |
| Model | HCPL-2300-000E |
| Mount Type | Through Hole |
| Series | HCPL |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 1mA |
| Number Of Channels | 1 |
| Standards/Approvals | IEC/EN/DIN EN 60747-5-5, CSA, UL 1577 |
| Maximum Forward Voltage | 1.65V |
| Number of Pins | 8 |
| Input Current Type | DC |
| Typical Rise Time | 40ns |
| Typical Fall Time | 20ns |
| Isolation Voltage | 3750V ac |
Key Features
- Designed for DC input applications with a maximum forward voltage of 1.65 volts.
- Features a single channel with 8-pin dual inline package mounting.
- Typical rise time is 40 nanoseconds, and typical fall time is 20 nanoseconds for efficient switching.
- Maximum input current rating is 1 milliampere ensuring low power consumption.
- Rated for isolation voltage up to 3750 volts AC providing excellent signal isolation.
- Operates reliably between temperatures of -40°C to 85°C suitable for various environments.
- Complies with IEC/EN/DIN EN 60747-5-5, CSA, and UL 1577 standards ensuring safety and quality.
- Logic output integrated for easy interfacing with digital circuits.
Product Description
Broadcom HCPL-2300-000E is a high-performance DC input optocoupler featuring a through-hole mount and an 8-pin dual inline package (DIP). This device provides reliable optical isolation for signal transmission where electrical isolation and high noise immunity are critical.
Ideal for industrial and electronic applications, the HCPL-2300-000E supports a maximum forward voltage of 1.65 volts at its input LED and a maximum input current of 1 milliampere which ensures minimal power dissipation. It incorporates a single channel with rapid response times, having a typical rise time of 40 nanoseconds and fall time of 20 nanoseconds to support high-speed switching requirements.
The optocoupler is rated for an isolation voltage of 3750 volts AC, effectively isolating input and output sides to safeguard sensitive components from high voltages. It operates in a wide temperature range from -40°C to 85°C, making it suitable for harsh industrial and commercial environments.
This product meets stringent international standards including IEC/EN/DIN EN 60747-5-5 and approvals from CSA and UL 1577, guaranteeing safe and reliable performance. Its logic output feature facilitates straightforward integration into digital and logic circuitry designs.
Common use cases include isolation in power supplies, microprocessor system interfaces, digital circuitry isolation, and industrial automation where precise signal transmission isolation is critical.
Designed for DC input applications with a maximum forward voltage of 1.65 volts. Features a single channel with 8-pin dual inline package mounting. Typical rise time is 40 nanoseconds, and typical fall time is 20 nanoseconds for efficient switching.
Maximum input current rating is 1 milliampere ensuring low power consumption. Rated for isolation voltage up to 3750 volts AC providing excellent signal isolation. Operates reliably between temperatures of -40°C to 85°C suitable for various environments.
Complies with IEC/EN/DIN EN 60747-5-5, CSA, and UL 1577 standards ensuring safety and quality. Logic output integrated for easy interfacing with digital circuits. Explore more Optocouplers and electronic components from Broadcom and other leading suppliers on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward voltage for the HCPL-2300-000E is 1.65 volts.
The typical rise time of this optocoupler is 40 nanoseconds.
This model has a maximum input current rating of 1 milliampere.
The HCPL-2300-000E is rated for an isolation voltage of up to 3750 volts AC.
It operates reliably between temperatures of -40°C to 85°C.
This model features a single channel.
The optocoupler is designed for through-hole mounting.
It comes in an 8-pin dual inline package (DIP).
It complies with IEC/EN/DIN EN 60747-5-5, CSA, and UL 1577 standards.
The typical fall time is 20 nanoseconds.
This optocoupler is suitable for isolation in power supplies, microprocessor system interfaces, and industrial automation.
The input current type for this model is DC.
