Broadcom DC Input Optocoupler Surface Mount 8-Pin SOIC Package 3750V Isolation Voltage HCPL-0201-000E

Broadcom HCPL-0201-000E DC Input Optocoupler is a single-channel optocoupler designed for surface mounting on PCBs using an 8-pin SOIC package. It provides galvanic isolation with a high isolation voltage rating of 3750V AC, ensuring effective protective separation between input and output circuits. This component is ideal for industrial, electronics manufacturing, and instrumentation applications where signal isolation and reliable digital interface are required.

Featuring a maximum forward voltage of 1.85V and supporting a maximum input current of 10mA DC, the device is suited for low-drive control circuit integration. The fast typical rise time of 30ns and fall time of 7ns enable rapid digital signal transmission and reduced signal latency, benefiting high-speed interface designs.

The optocoupler operates consistently across a broad temperature range of -40°C to 85°C, allowing use in harsh environments and temperature-sensitive applications. The device output provides a logic-compatible signal to facilitate straightforward digital control, isolation, and signal protection against high-voltage transients and noise.

Broadcom supplies this component on tape and reel packaging, supporting automated pick-and-place assembly for high-volume industrial production. It adheres to IEC/EN/DIN EN 60747-5-2, UL1577, and CSA safety approvals, underscoring its suitability for stringent industrial standards. The SOIC surface mount design ensures compact integration on PCBs for electronic equipment across diverse sectors such as industrial control, power electronics, and instrumentation.

Provides 3750V AC isolation voltage for effective circuit protection. Features fast signal transitions with a 30ns typical rise time and 7ns fall time. Supports a maximum input current of 10mA with 1.85V forward voltage.

Encased in an 8-pin SOIC surface mount package suitable for automated PCB assembly. Operates reliably over a wide temperature range from -40°C to 85°C. Logic output is compatible with digital interfaces for effective signal transmission.

Packaged on tape and reel to enable high-volume production processes. Complies with IEC/EN/DIN EN 60747-5-2, UL1577, and CSA safety standards.

This product is essential for industrial electronic designs requiring isolation of microcontroller logic from power stages, protection of sensitive measurement circuitry, and reliable digital interface level translation. Its compliance with rigorous safety standards and suitability for tape and reel assembly make it highly applicable for mass production in electronics manufacturing.
