KEMET PHE450 Film Capacitor 2.2 nF ±5 % 2 kV DC 180 V AC Through Hole Radial Terminal

The KEMET PHE450 Film Capacitor model PHE450SB4220JR06 is a high-quality, double metallized polypropylene film capacitor engineered for demanding electrical and electronic applications. Featuring a capacitance value of 2.2 nF with a ±5 % tolerance, this capacitor is designed for precision in pulse and snubber circuits commonly found in switch mode power supplies and television deflection circuits.

This capacitor supports a rated DC voltage of 2 kV and a rated AC voltage of 180 V, permitting operation in environments requiring significant electrical stress tolerance. Its construction includes a radial terminal type designed for through hole mounting with a lead pitch of 15 mm and lead length of 6 mm coupled with a lead diameter of 0.8 mm, ensuring secure and reliable PCB connections.

Encased in a self-extinguishing resin box meeting the UL 94 V-0 flammability standard, the PHE450 offers enhanced safety and durability in challenging industrial environments. Its operating temperature range from -55 °C to 105 °C broadens applicability to various thermal conditions.

The capacitor comes packaged in tape and reel form, supporting efficient automated manufacturing processes. Dimensions are 18 mm in length, 10.5 mm in height, and 5.5 mm in width, making it compact for integration into dense electronic assemblies.

Its extremely low dissipation factor of 0.0003 % contributes to high efficiency and minimal energy loss. KEMET is a trusted brand recognized for its commitment to quality and reliability in passive electronic components.

Metallized polypropylene film construction with double metallization for enhanced performance. ±5 % capacitance tolerance suitable for precision electronic designs. Rated DC voltage of 2 kV and AC voltage of 180 V for demanding applications.

Radial lead mounting style with 15 mm lead pitch optimizes PCB layout flexibility. Wide operating temperature from -55 °C to 105 °C allows robust use in industrial and commercial electronics. UL 94 V-0 compliant resin encapsulation ensures safety and flame resistance.

Low dissipation factor reduces power losses and heat generation. Tape and reel packaging supports automated assembly lines. Compact dimensions enable integration into limited space circuits.

This film capacitor is ideal for industrial, commercial, and consumer electronics applications, particularly in power supply filtering, pulse handling, and snubber circuits. KEMET’s PHE450 series continues to meet the evolving demands of modern electronic design with reliability and excellent electrical characteristics.

Whether you are designing high-frequency switch mode power supplies or high voltage pulse circuits, the KEMET PHE450SB4220JR06 Film Capacitor provides precise, durable, and compliant performance.
