Wurth Elektronik Angled Surface PCB Socket 14-Contact 2 Row 2 mm Pitch 200V 2A WR-PHD Series 621114284621
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Angled |
| Current | 2A |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Withstanding Voltage | 500 V (AC) |
| Insulator Material | LCP |
Key Features
- Features solder termination for secure and reliable connections.
- Constructed with liquid crystal polymer housing for durability.
- Supports operating temperatures from -40°C to 105°C.
- Rated for 2A current and 200V voltage applications.
- Gold-plated copper alloy female contacts ensure excellent conductivity.
- Designed with an angled orientation suitable for compact PCB layouts.
- Complies with WR-PHD series specifications by Wurth Elektronik.
- Manufactured in China with LCP insulator and 500 V AC withstand voltage rating.
Product Description
Wurth Elektronik 621114284621 is an angled surface mount printed circuit board (PCB) socket designed for reliable board-to-board connections. It features 14 female contacts arranged in 2 rows with a 2 mm pitch, making it suitable for a variety of electronic component assemblies requiring compact and secure interconnections.
The socket’s housing is made of liquid crystal polymer (LCP), which provides excellent mechanical strength and thermal stability. It supports a wide operating temperature range from -40°C to +105°C, ensuring performance in demanding industrial and consumer electronics applications.
The copper alloy contacts are plated with gold, enhancing conductivity and corrosion resistance, and the socket is rated for current up to 2 amps and voltage up to 200 volts. Its solder termination type ensures a stable and lasting connection to the PCB.
With a withstand voltage of 500 V AC, this PCB socket is suitable for use in a variety of electronic systems requiring robust performance under electrical stress. The angled orientation design facilitates flexibility in PCB layout and assembly.
Features solder termination for secure and reliable connections. Constructed with liquid crystal polymer housing for durability. Supports operating temperatures from -40°C to 105°C. Rated for 2A current and 200V voltage applications.
Gold-plated copper alloy female contacts ensure excellent conductivity. Designed with an angled orientation suitable for compact PCB layouts. Complies with WR-PHD series specifications by Wurth Elektronik. Manufactured in China with LCP insulator and 500 V AC withstand voltage rating.
This PCB socket is ideal for industrial electronics, power supplies, control systems, and manufacturing applications requiring durable and precise board connections. It supports a wide temperature range and offers high reliability in surface mount configurations.
Explore EnvMart for a broad range of PCB Sockets and connectors from top electrical component manufacturers like Wurth Elektronik.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB socket is 200V.
This model is rated for a current of up to 2A.
The housing of this PCB socket is constructed from liquid crystal polymer (LCP).
It features a 2 mm pitch with 14 female contacts arranged in 2 rows.
The operating temperature range for this PCB socket is from -40°C to +105°C.
This socket uses a solder termination type for secure connections.
The withstanding voltage rating for this PCB socket is 500 V AC.
This model has an angled orientation, suitable for compact PCB layouts.
The contacts are made of copper alloy and are gold-plated for enhanced conductivity.
This PCB socket is manufactured in China.
It is suitable for industrial electronics, power supplies, control systems, and manufacturing applications.
This socket has 2 rows of contacts.
