Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket 6-Contact 2 Row 2.54 mm Pitch 500V 3A 613006216921

Name: Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket 6-Contact 2 Row 2.54 mm Pitch 500V 3A 613006216921
Brand: Wurth Elektronik
SKU: 190310
Price: 1.76 USD
Availability: InStock



Category PCB Sockets Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	500V
Brand	Wurth Elektronik
Orientation	Bottom Entry
Current	3A
Mount Type	Through Hole
Contact Material	Copper Alloy
Series	WR-PHD
Durability	25mating cycles
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	PCB Socket
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	6
Connector System	Board-to-Board

Key Features

Features a 2.54 mm pitch and dual row 6-contact configuration.
Constructed with copper alloy contacts plated in gold for enhanced conductivity.
Rated for a current of 3A and voltage of up to 500V.
Mount type is through hole with bottom entry orientation for secure soldering.
Durable design supports up to 25 mating cycles ensuring longevity.
Operating temperature range spans from -40°C to 105°C for varied environments.
Manufactured with Nylon 9T insulator material exhibiting UL94 V-0 flammability rating.
Complies with RoHS standards and is UL approved (E323964).

Product Description

Wurth Elektronik 613006216921 Bottom Entry Through Hole PCB Socket is engineered for industrial and electronic applications requiring robust board-to-board connectors. This model features a 6-contact, 2-row layout with a precise 2.54 mm pitch, ensuring compatibility with standard PCBs.

The contacts are made of copper alloy with a gold plating to provide excellent electrical conductivity and resistance to corrosion. The socket supports a current rating of 3A and withstands voltages up to 500V.

The socket is a through hole mount type with bottom entry orientation, facilitating easy soldering and stable mechanical connection. It is built with a Nylon 9T insulator material which offers high durability and meets UL94 V-0 flammability standards, making it suitable for demanding industrial environments.

The product operates reliably in temperatures ranging from -40°C to 105°C and endures up to 25 mating cycles, offering long-term performance. Certified for RoHS compliance and UL approval (E323964), this socket aligns with industry requirements for safety and environmental standards.

Features a 2.54 mm pitch and dual row 6-contact configuration. Constructed with copper alloy contacts plated in gold for enhanced conductivity. Rated for a current of 3A and voltage of up to 500V. Mount type is through hole with bottom entry orientation for secure soldering.

Durable design supports up to 25 mating cycles ensuring longevity. Operating temperature range spans from -40°C to 105°C for varied environments. Manufactured with Nylon 9T insulator material exhibiting UL94 V-0 flammability rating.

Complies with RoHS standards and is UL approved (E323964).

This PCB socket is suited for electronics manufacturing, industrial control systems, and other commercial applications requiring reliable electrical connections. Explore our extensive range of electronic components at EnvMart for additional PCB Sockets and connectors.
