| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.6mm |
| Length | 3.7mm |
| Model | BZV55-C5V6,115 |
| Mount Type | Surface |
| Series | BZV55 |
| Maximum Operating Temperature | 200°C |
| Package Type | SOD-80 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 5.6V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 40Ω |
| Typical Voltage Temperature Coefficient | 1.2mV/°C |
The Nexperia BZV55-C5V6,115 is a precision single Zener diode optimized for voltage regulation applications in electronic circuits. Featuring a nominal Zener voltage of 5.6 volts and a maximum power dissipation of 500 milliwatts, this diode is designed for surface mounting in a compact 2-pin SOD-80 package, facilitating easy integration into dense PCB layouts.
This diode offers stable voltage regulation with a tolerance of ±5% and a low maximum reverse leakage current of just 1 microampere, minimizing power loss when reverse biased. Its robust operating temperature range from -65°C to 200°C makes it suitable for industrial, automotive, and general electronics applications requiring reliability under diverse environmental conditions.
The device has a typical voltage temperature coefficient of 1.2 mV/°C, ensuring consistent performance across temperature variations. With maximum Zener impedance of 40 ohms, it maintains voltage stability even under varying load conditions.
Its small height of 1.6 mm and length of 3.7 mm enable compact assemblies for modern electronics where space saving is critical. The test current of 5 mA is the standard for confirming its specified Zener voltage voltage regulation capabilities.
Applications include power supplies protection, voltage regulation for circuits, and reference voltage creation in a broad spectrum of electronics from telecommunications to automotive electronics.
Nominal Zener voltage of 5.6 V with ±5% tolerance. 500 mW maximum power dissipation for medium power regulation needs. Surface mount, 2-pin SOD-80 package for automated PCB assembly. Maximum reverse leakage current of 1 μA ensures efficiency.
Wide temperature range from -65°C to 200°C supports harsh environments. Typical voltage temperature coefficient of 1.2 mV/°C for stable performance. Compact size with 1.6 mm height and 3.7 mm length saves board space. Voltage regulator type Zener diode from the BZV55 series by Nexperia.
Ideal for industrial, automotive, and electronic applications requiring precise voltage regulation. Explore more such semiconductor components by browsing other Zener Diodes and related products on EnvMart.
