Nexperia 15 V Zener Diode Single 1 W 5% Surface Mount 4-Pin UPAK BZV49-C15,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.6mm |
| Length | 4.6mm |
| Model | BZV49-C15,115 |
| Mount Type | Surface |
| Series | BZV49 |
| Maximum Operating Temperature | 150°C |
| Package Type | UPAK |
| Minimum Operating Temperature | -65°C |
| Pin Count | 4 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 1W |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 15V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 30Ω |
| Typical Voltage Temperature Coefficient | 11.4mV/°C |
Key Features
- Nominal Zener voltage of 15 V ensures stable voltage regulation.
- Single diode configuration with 4-pin surface mount UPAK package.
- Maximum power dissipation rated at 1 W for reliable performance.
- Operating temperature range from -65°C to 150°C for extended durability.
- Maximum reverse leakage current limited to 50 nA to minimize leakage losses.
- Typical voltage temperature coefficient of 11.4 mV/°C for temperature stability.
- Compact dimensions with length 4.6 mm and height 1.6 mm facilitates PCB space savings.
- Maximum Zener impedance of 30 Ω reduces noise and improves performance.
Product Description
Nexperia BZV49-C15,115 is a single Zener diode designed for precise voltage regulation with a nominal Zener voltage of 15 V, and a maximum power dissipation of 1 W. It features a surface mount 4-pin UPAK package which enables efficient PCB mounting in compact electronic circuits.
This diode has a voltage tolerance of ±5%, which ensures accuracy in voltage regulation across various applications. It operates reliably over a wide temperature range from -65°C to 150°C, making it suitable for robust industrial and commercial electronics environments.
The maximum reverse leakage current is limited to 50 nA, promoting energy efficiency by minimizing leakage losses. Its typical voltage temperature coefficient of 11.4 mV/°C aids in stabilization against temperature variations during operation.
Compact physical dimensions (4.6 mm length, 1.6 mm height) are ideal for space-constrained PCB designs. The maximum Zener impedance of 30 Ω helps reduce electrical noise, improving overall circuit performance.
This product is widely used in industrial, laboratory, and commercial electronic applications for voltage regulation, protection circuits, and semiconductor device stabilization. The diode belongs to the BZV49 series from Nexperia, known for quality and reliability in discrete semiconductor components.
Nominal Zener voltage: 15 V. Power dissipation: 1 W. Voltage tolerance: ±5%. Package type: Surface mount 4-pin UPAK. Operating temperature range: -65°C to 150°C. Max reverse leakage current: 50 nA. Typical voltage temp coefficient: 11.4 mV/°C.
Max Zener impedance: 30 Ω. Dimensions: 4.6 mm length x 1.6 mm height. Choose Nexperia BZV49-C15,115 Zener diode for reliable voltage regulation in electronics manufacturing and repair. Explore more semiconductor components on EnvMart.
Explore more products in our Zener Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal Zener voltage of this diode is 15 V, ensuring stable voltage regulation.
The maximum power dissipation rated for this model is 1 W, allowing for reliable performance in various applications.
It operates over a wide temperature range from -65°C to 150°C, making it suitable for robust industrial and commercial environments.
The maximum reverse leakage current is limited to 50 nA, which helps minimize leakage losses and improve energy efficiency.
This model has compact dimensions of 4.6 mm in length and 1.6 mm in height, facilitating PCB space savings.
It features a surface mount 4-pin UPAK package, which enables efficient PCB mounting in compact electronic circuits.
The typical voltage temperature coefficient is 11.4 mV/°C, aiding in stabilization against temperature variations during operation.
This model has a single diode configuration, meaning there is 1 element per chip.
The maximum Zener impedance is 30 Ω, which helps reduce electrical noise and improve overall circuit performance.
It is widely used in industrial, laboratory, and commercial electronic applications for voltage regulation and protection circuits.
This diode belongs to the BZV49 series from Nexperia, known for quality and reliability in discrete semiconductor components.
The test current for this model is 5 mA, which is used for its performance evaluation.
