Wurth Elektronik 1317 Series 2-Contact 5 mm Pitch PCB Terminal Block Through Hole 1 Row 691131710002
Specifications
| Country of Origin | Hungary |
|---|---|
| Voltage | 450V ac |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | Horizontal |
| Current | 22A |
| Length | 10mm |
| Depth | 15.5mm |
| Width | 8.5mm |
| Mount Type | Through Hole |
| Series | 1317 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | VDE, RoHS, cULus |
| Number of Contacts | 2 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
Key Features
- This PCB terminal block supports a current rating of 22A for efficient electrical conduction.
- It features a horizontal orientation and uses a pressure clamp system with M2.5 screws for secure wire connections.
- The terminal block accommodates wire sizes from 30 AWG to 12 AWG, with a wire cross-section range of 0.05 mm² to 3.31 mm².
- Constructed from grey UL94-V0 polycarbonate housing, it ensures flame retardance and durability.
- The compact size includes dimensions of 10 mm length, 8.5 mm width, and 15.5 mm depth suitable for PCB mounting.
- Operates safely up to 450V AC voltage, meeting VDE, RoHS, and cULus standards.
- Manufactured in Hungary, this terminal block series 1317 is ideal for electronics and power connector applications.
Product Description
Wurth Elektronik 691131710002 is a 1317 Series PCB Terminal Block featuring a 2-contact design with a 5 mm pitch and through-hole mount type for reliable PCB integration. This terminal block is engineered for horizontal wire entry and utilizes a pressure clamp system with M2.5 screws and zinc-plated steel clamps to ensure secure and stable electrical connections in a variety of electronic assemblies.
The housing is made from grey UL94-V0 flame-retardant polycarbonate, providing high durability and safety against electrical hazards. It supports a current load of 22A and can accommodate wire sizes ranging from 30 AWG to 12 AWG (0.05 to 3.31 mm²), suitable for most wire types in industrial and commercial electronic applications.
Compactly measuring 10 mm in length, 8.5 mm in width, and 15.5 mm in depth, the terminal block is designed for seamless PCB mounting while maintaining secure electrical contact at up to 450V AC. It complies with industry standards including VDE, RoHS, and cULus, ensuring high product quality and certification adherence.
This product is manufactured in Hungary and belongs to the 1317 series of Wurth Elektronik terminal blocks. It is a perfect choice for use in electronic components, power connectors, and terminal block assemblies across industrial, laboratory, and commercial electronics sectors.
This PCB terminal block supports a current rating of 22A for efficient electrical conduction. It features a horizontal orientation and uses a pressure clamp system with M2.5 screws for secure wire connections. The terminal block accommodates wire sizes from 30 AWG to 12 AWG, with a wire cross-section range of 0.05 mm² to 3.31 mm².
Constructed from grey UL94-V0 polycarbonate housing, it ensures flame retardance and durability. The compact size includes dimensions of 10 mm length, 8.5 mm width, and 15.5 mm depth suitable for PCB mounting. Operates safely up to 450V AC voltage, meeting VDE, RoHS, and cULus standards.
Manufactured in Hungary, this terminal block series 1317 is ideal for electronics and power connector applications. Explore more Wurth Elektronik products and PCB Terminal Block solutions in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 22A, allowing for efficient electrical conduction in various applications.
It operates safely at a maximum voltage of 450V AC, making it suitable for high-voltage applications.
It accommodates wire sizes ranging from 30 AWG to 12 AWG, with a wire cross-section range of 0.05 mm² to 3.31 mm².
The terminal block measures 10 mm in length, 8.5 mm in width, and 15.5 mm in depth, making it compact for PCB mounting.
It features a through-hole mount type, designed for reliable integration onto PCBs.
The housing is constructed from grey UL94-V0 polycarbonate, which is flame-retardant and durable.
It meets several industry standards including VDE, RoHS, and cULus, ensuring quality and safety compliance.
It uses a pressure clamp system with M2.5 screws and zinc-plated steel clamps for secure wire connections.
The terminal block features a horizontal orientation for wire entry, facilitating easier connections.
This terminal block is part of the 1317 series from Wurth Elektronik, designed for various electronic applications.
It is manufactured in Hungary, ensuring adherence to quality standards during production.
This model features 2 contacts, allowing for dual connections in electronic assemblies.
