Panasonic ECWFE Film Capacitor, ±5 % Tolerance, 220 nF 450 V DC Radial Through Hole ECWFE2W224J

Name: Panasonic ECWFE Film Capacitor, ±5 % Tolerance, 220 nF 450 V DC Radial Through Hole ECWFE2W224J
Brand: Panasonic
SKU: 183042
Price: 0.33 USD
Availability: InStock



Category Film Capacitor Brand Panasonic Condition New

Specifications

Country of Origin	China
Brand	Panasonic
Height	12mm
Length	13mm
Model	ECWFE2W224J
Packaging	Bag
Width	6mm
Mount Type	Through Hole
Series	ECWFE
Maximum Operating Temperature	105°C
Tolerance	±5 %
Capacitance	220nF
Minimum Operating Temperature	-40°C
Terminal type	Radial
Dissipation Factor	0.1%
Lead Length	20mm
Rated DC Voltage	450V dc
Lead Pitch	10mm
Lead Diameter	0.6mm
Automotive Standard	AEC-Q200

Key Features

Features a radial terminal type with through-hole mount for reliable PCB assembly.
Constructed with a flame retardant, non-combustible epoxy resin case ensuring safety and durability.
Equipped with a built-in fuse and failsafe design to prevent short circuits by opening upon failure.
Offers excellent frequency characteristics and low dissipation factor of 0.1 % for enhanced performance.
Suitable for high frequency and active filter circuits, providing low hum noise and vibration resistance.
Rated for operation between -40°C and 105°C, complying with automotive standard AEC-Q200.
Compact dimensions with 12 mm height, 13 mm length, 6 mm width, 20 mm lead length, and 10 mm lead pitch.
Encapsulated in self-extinguishing materials meeting UL94V-0 requirements.

Product Description

Panasonic ECWFE2W224J film capacitor is a metallised polypropylene film capacitor rated for 450 V DC applications, featuring a ±5 % tolerance and a capacitance of 220 nF. It is designed with a radial terminal type and through-hole mounting suitable for robust PCB integration. The capacitor case is flame retardant with non-combustible epoxy resin providing durability and safety in demanding environments.

This capacitor series incorporates a built-in fuse and failsafe mechanism that prevents short circuits by opening upon failure. Its polypropylene dielectric material ensures superior electrical characteristics compared to polyester dielectrics, with a dissipation factor of just 0.1 % providing excellent frequency response and low loss.

Operating temperature range spans from -40°C up to 105°C, and it meets automotive standard AEC-Q200, UL 60384-14, EN 60384-14, and CSA E60384-14 approvals. The compact form factor with dimensions of 12 mm height, 13 mm length, and 6 mm width plus 20 mm lead length and 10 mm lead pitch supports space-efficient circuit board design.

ECWFE capacitors are suitable for high frequency circuits, active filter circuits, and high current applications where vibration resistance and low noise are critical. Their construction includes self-extinguishing materials compliant with UL94V-0 standards, making them ideal for industrial automation, IT systems, alternative energy sectors, power supplies, power factor correction (PFC), servers, and automation equipment where reliability under vibration is essential.

Radial terminal, through-hole mount construction. Built-in fuse and failsafe design preventing short circuits. Flame retardant epoxy resin case for enhanced safety. Low dissipation factor of 0.1 % and excellent frequency characteristics.

Industrial-grade temperature range from -40°C to 105°C. Meets automotive AEC-Q200 and multiple UL/EN/CSA standards. Compact size optimized for PCB installations. Suitable for active filter and high frequency circuit applications.

Self-extinguishing material complies with UL94V-0 standard. Explore more Panasonic Film Capacitors and electronics components in the EnvMart catalog to support your industrial, manufacturing, or electronic design needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The Panasonic ECWFE2W224J film capacitor has a capacitance of 220 nF and is rated for 450 V DC applications.

It operates within a temperature range of -40°C to 105°C, making it suitable for various environments.

This model features a low dissipation factor of 0.1%, which contributes to its excellent frequency characteristics.

The capacitor is designed for through-hole mounting, which is suitable for robust PCB assembly.

The capacitor has a height of 12 mm, a length of 13 mm, and a width of 6 mm, with a lead length of 20 mm and a lead pitch of 10 mm.

Yes, it meets the automotive standard AEC-Q200, ensuring its reliability in automotive applications.

It is constructed with a flame retardant, non-combustible epoxy resin case, ensuring safety and durability.

It is equipped with a built-in fuse and a failsafe design that prevents short circuits by opening upon failure.

This model is suitable for high frequency circuits, active filter circuits, and high current applications where low noise and vibration resistance are critical.
