Panasonic ECWFE Film Capacitor, 470 nF Capacitance, ±5 % Tolerance, 630 V DC Rated Voltage, Through Hole Mount ECWFE2J474JA
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 15.5mm |
| Length | 17.5mm |
| Model | ECWFE2J474JA |
| Packaging | Bag |
| Width | 10mm |
| Mount Type | Through Hole |
| Series | ECWFE |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 470nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Radial |
| Dissipation Factor | 0.1% |
| Lead Length | 4mm |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- Manufactured with high-quality polypropylene dielectric material ensuring low loss and superior frequency characteristics.
- Features built-in fuse technology for failsafe operation preventing short circuits upon failure.
- Designed for active filter and high-frequency circuits, suitable for industrial automation and alternative energy sectors.
- Radial terminal type with 15 mm lead pitch and 4 mm lead length providing reliable through hole mounting.
- Operating temperature ranges from -40°C to 105°C, with flame retardant, self-extinguishing epoxy resin casing meeting UL94V-0 standards.
- Compact dimensions of 17.5 mm length, 15.5 mm height, and 10 mm width optimize space usage on PCBs.
- Compliant with automotive standard AEC-Q200 and international safety approvals CSA E60384-14, EN 60384-14, UL 60384-14.
Product Description
Panasonic ECWFE2J474JA Film Capacitor is a metallised polypropylene film capacitor engineered to deliver excellent electrical performance with a capacitance of 470 nF and a dc voltage rating of 630V. Its ±5 % tolerance and low dissipation factor of 0.1% make it ideal for precision applications in active filters and high frequency circuits, ensuring signal integrity and minimal power loss.
The robust through hole radial design with a 15 mm lead pitch and 4 mm lead length facilitates secure PCB mounting. The capacitor casing is flame retardant with a non-combustible epoxy resin, conforming to UL94V-0, enhancing safety in harsh industrial environments.
The ECWFE series incorporates a built-in fuse failsafe design which opens upon failure instead of short circuiting, ensuring reliability and protection of downstream circuitry. Its polypropylene dielectric ensures superior electrical characteristics compared to polyester dielectrics, contributing to excellent frequency response and low noise operation.
Rated for temperatures from -40°C to 105°C and meeting automotive AEC-Q200 standards, this capacitor is suitable for industrial automation, IT equipment, servers, and alternative energy applications where vibration resistance and reliability are critical.
Manufactured with high-quality polypropylene dielectric. Built-in fuse and failsafe operation to prevent short circuits. Compact and robust flame retardant casing. Wide operating temperature range and automotive standard compliance.
Optimal for high frequency and active filter circuits. Complies with CSA, EN, and UL safety standards.
The product originates from China and comes packaged in a bag format. Panasonic film capacitors provide dependable performance and are widely used in commercial and industrial electronic applications.
For dependable and precision film capacitors, browse Panasonic products and other Film Capacitor options in the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 470 nF.
It has a rated DC voltage of 630 V.
The tolerance for this capacitor is ±5 %.
The operating temperature range is from -40°C to 105°C.
It uses a through hole mounting type with a radial terminal configuration.
The dimensions are 17.5 mm in length, 15.5 mm in height, and 10 mm in width.
The lead length is 4 mm and the lead pitch is 15 mm.
The dissipation factor is 0.1%.
It complies with the automotive standard AEC-Q200.
The casing meets UL94V-0 standards, ensuring it is flame retardant and self-extinguishing.
It is suitable for active filter and high-frequency circuits, particularly in industrial automation and alternative energy sectors.
This model is packaged in a bag format.
