Nexperia Small Signal 100 mA NPN Transistor, 65 V, 3-Pin SOT-23 Package BC846B,215

Nexperia BC846B,215 is a high-quality small signal NPN transistor suitable for electronic circuit applications requiring reliable switching and amplification in compact designs. The transistor is rated for a maximum collector current of 100 mA and can withstand a maximum collector emitter voltage of 65 V.

It is housed in a small 3-pin SOT-23 surface mount package with dimensions of 3 mm length, 2.5 mm width, and 1.1 mm height, making it ideal for compact PCB layouts. The transistor offers a minimum DC current gain of 200 that supports efficient signal amplification.

This device operates over a wide temperature range from -65°C to 150°C and supports a transition frequency up to 100 MHz, suitable for high-frequency switching applications. Its maximum power dissipation is rated at 500 mW, ensuring robust thermal performance under typical operating conditions.

The transistor complies with RoHS environmental standards, guaranteeing environmentally safe materials and manufacturing processes.

Commonly used in electronic, power, and semiconductor circuit designs, the Nexperia BC846B,215 transistor finds applications in signal amplification, switching, and low-power load driving in industrial, automotive, and consumer electronics sectors.

This transistor supports a maximum collector base voltage of 80 V and maximum power dissipation of 500 mW. It features a minimum DC current gain (hFE) of 200 and a maximum emitter base voltage of 6 V. The package dimensions are compact with length 3 mm, width 2.5 mm, and height 1.1 mm.

Designed for surface mount applications with a transistor configuration of single NPN. Operating temperature ranges from -65°C to 150°C with a transition frequency up to 100 MHz. Complies with RoHS standards ensuring environmental safety and reliability.
