Samtec TMS Series Right Angle Through Hole Pin Header, 20 Contacts, 1.27 mm Pitch, 2 Row, Unshrouded TMS-110-01-S-D-RA
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 1A |
| Model | TMS-110-01-S-D-RA |
| Mount Type | Through Hole |
| Housing Material | Polymer |
| Contact Material | Phosphor Bronze |
| Series | TMS |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 1.27mm |
| Mating Pin Length | 3.2mm |
Key Features
- Constructed with polymer housing providing durable insulation.
- Features gold-plated phosphor bronze male contacts ensuring reliable conductivity.
- Designed for board-to-board connection with through-hole mounting.
- Operates within a temperature range of -55°C to 105°C suitable for industrial environments.
- Tail pin length of 1.27 mm and mating pin length of 3.2 mm for secure soldering.
- Current rated up to 1 Amp supporting standard PCB power requirements.
- Right angle orientation enables compact PCB designs and efficient space usage.
- Unshrouded style allows for easy inspection and maintenance of connections.
Product Description
Samtec TMS-110-01-S-D-RA is a Right Angle Through Hole Pin Header featuring 20 male contacts arranged in 2 rows with a 1.27 mm pitch. It is part of the TMS series designed for board-to-board connections in electronic assemblies, made for soldering onto PCBs through through-hole mounting.
The polymer housing provides robust insulation and mechanical support, while the phosphor bronze contacts plated with gold ensure excellent electrical conductivity and corrosion resistance. These headers support currents up to 1 Amp and operate effectively within a temperature range of -55°C to 105°C, making them suitable for a wide variety of industrial and commercial electronic applications.
The right-angle orientation facilitates space-saving configurations on printed circuit boards, enhancing design flexibility. The unshrouded contact style allows visual access for inspection and troubleshooting. Tail pins measure 1.27 mm in length with mating pins of 3.2 mm for reliable solder connection integrity.
This pin header is ideal for use in electronic component assembly, PCB manufacturing, and repair operations requiring high quality and dependable connectors. Its specifications meet standard industry requirements but do not carry specific certifications.
Constructed with polymer housing for electrical insulation. Gold-plated phosphor bronze contacts for enhanced conductivity. 20 contacts arranged in 2 rows with 1.27 mm pitch. Current rating of 1 Amp suitable for standard applications.
Right angle orientation for compact PCB layout designs. Through hole mount type for secure PCB attachment. Operates across a wide temperature range from -55°C to 105°C. Unshrouded design for easy maintenance and inspection.
This product is listed under Electronics Components category, perfect for industrial, manufacturing and laboratory use involving PCB assembly and connectivity solutions. Explore more Samtec connectors and related components on EnvMart for comprehensive sourcing.
Explore more products in our PCB Connectors & Wire Housings category.
