Microchip Low Dropout Voltage Regulator 28V 150mA Surface Mount SOT-23 5-Pin MCP1804T-C002I/OT

Microchip MCP1804T-C002I/OT Low Dropout (LDO) Voltage Regulator provides highly efficient voltage regulation with a wide input range from 2.0 V to 28.0 V and a maximum output current of 150 mA. Designed in a compact 5-pin SOT-23 surface mount package, this device is optimized for applications requiring low power consumption and stable voltage supply.

The regulator maintains low quiescent current of 50 μA typically, making it ideal for battery-powered and portable electronics. Its low dropout voltage of 260 mV at 20 mA ensures minimal voltage loss and reliable regulation down to voltages near the output level.

The device features built-in current limit protection with foldback to safeguard against overload and thermal damage. Its shutdown pin enables the device to enter an ultra-low current mode with just 0.01 μA shutdown current, preventing unnecessary power drain in standby states.

Microchip MCP1804T-C002I/OT achieves high power supply rejection ratio (PSRR) of 50 dB at 1 kHz frequency, effectively filtering input voltage noise and enhancing output stability. It is stable with ceramic output capacitors of just 1 μF, supporting compact and lightweight PCB design.

This voltage regulator supports operation up to 85°C ambient temperatures, making it suitable for a range of industrial, consumer electronics, automotive, and instrumentation applications. The small SOT-23 package with dimensions approximately 3.1 mm length, 1.8 mm width, and 1.3 mm height facilitates space-saving layouts in dense electronics systems.

Package Contents: 1 Pc Microchip MCP1804T-C002I/OT Voltage Regulator in SOT-23 5-pin package.

EnvMart offers this Voltage Regulator as a reliable solution for power management in electronic circuit designs requiring stable and efficient voltage regulation with low dropout features.
