Nexperia 8-bit Serial-In Serial or Parallel-Out Shift Register with Storage Register and 3-State Outputs 16-Pin 74HC595BZX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4.9mm |
| Model | 74HC595BZX |
| Width | 4.3mm |
| Mount Type | Surface |
| Series | 74HC595 |
| Maximum Operating Temperature | 125°C |
| Standards/Approvals | JEDEC, RoHS |
| Pin Count | 16 |
| Maximum Supply Voltage | 6V |
| Logic Family | 74HC |
| Minimum Supply Voltage | 2V |
Key Features
- Operates with a wide supply voltage range from 2.0 to 6.0 volts.
- Features separate shift and storage registers with independent clocks for precise data control.
- Includes serial input and serial output pins for cascading multiple devices.
- Supports asynchronous reset with a LOW on MR to clear the shift register.
- Provides low power CMOS operation and high noise immunity suitable for industrial use.
- Shift register data is clocked on LOW-to-HIGH transitions of the SHCP input for reliable timing.
- Data is transferred to the storage register on LOW-to-HIGH transition of the STCP input.
- Outputs enter a high-impedance state when output enable (OE) is HIGH, allowing bus sharing.
Product Description
Nexperia 74HC595BZX is an 8-bit serial-in/serial or parallel-out shift register with a storage register and 3-state outputs designed for surface mount applications on a 16-pin IC. Its wide supply voltage range of 2.0 to 6.0 V and maximum operating temperature of 125°C make it suitable for robust industrial and electronic applications.
The device features separate clocks for the shift and storage registers, enabling precise timing control. Data is shifted on the LOW-to-HIGH transition of the SHCP input and transferred to the storage register on the LOW-to-HIGH transition of the STCP input. Its serial input (DS) and serial output (Q7S) pins allow cascading multiple ICs for larger data storage or transfer operations.
An asynchronous reset input (MR) allows immediate clearing of the shift register when driven LOW. The output enable input (OE) controls the 3-state output drivers, entering a high-impedance state when HIGH, which is ideal for bus-oriented applications.
Nexperia’s 74HC595BZX uses CMOS technology for low power dissipation along with high noise immunity, supporting applications in industrial controls, instrumentation, communication devices, and digital logic systems.
The package dimensions (length 4.9 mm, width 4.3 mm, height 1.1 mm) and 16-pin surface mounting make it compact and suitable for modern PCB designs. Wide supply voltage range from 2.0 to 6.0 V for flexible powering. Separate shift and storage registers with independent clocks for accurate data handling.
Asynchronous reset input for immediate clearing of stored data. 3-state output drivers controlled by output enable for bus interfacing. Serial input/output for cascading multiple devices. Low power CMOS operation with high noise immunity.
This shift register IC is commonly used in industrial automation, digital logic circuits, electronic instrumentation, and embedded systems for data storage and transfer tasks. Explore more semiconductor and logic ICs in the EnvMart catalog for your electronic component needs.
Explore more products in our Latch ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 2.0 to 6.0 volts.
The maximum operating temperature for the 74HC595BZX is 125°C.
It features a total of 16 pins.
This unit supports surface mounting.
The dimensions are 4.9 mm in length, 4.3 mm in width, and 1.1 mm in height.
Yes, it includes serial input and serial output pins that allow for cascading multiple devices.
The asynchronous reset input (MR) allows for immediate clearing of the shift register when driven LOW.
Data is shifted on the LOW-to-HIGH transition of the SHCP input and transferred to the storage register on the LOW-to-HIGH transition of the STCP input.
This model complies with JEDEC and RoHS standards.
It uses CMOS technology for low power dissipation and high noise immunity.
It provides 3-state outputs controlled by an output enable (OE) input.
This shift register is commonly used in industrial automation, digital logic circuits, electronic instrumentation, and embedded systems.
