TDK Polyester Capacitor (PET) 1 nF 63V AC/DC Through Hole 2-Pin B32529C0102K289

Free Delivery in India | Lowest Global Shipping Charges

TDK Polyester Capacitor (PET) 1 nF 63V AC/DC Through Hole 2-Pin B32529C0102K289



Category Film Capacitors Brand TDK Condition New

Specifications

Country of Origin	Brazil
Brand	TDK
Height	6.5mm
Length	7.3mm
Model	B32529C0102K289
Width	2.5mm
Mount Type	Through Hole
Series	B32529
Maximum Operating Temperature	110°C
Capacitance	1nF
Standards/Approvals	UL, RoHS
Pin Count	2
Rated AC Voltage	63V ac
Rated DC Voltage	63V dc
Lead Pitch	5mm
Lead Diameter	0.5mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Capacitance of 1 nanofarad suitable for filtering and signal processing.
Rated for 63 volts AC and DC voltage operation.
Complies with automotive standard AEC-Q200 Rev D for high reliability.
Compact through-hole mount with 5 mm lead pitch and 2-pin configuration.
Constructed using metallized polyester film with epoxy sealing for durability.
Plastic case housing ensures protection and long-term stability.
Leads are made of lead-free tinned copper for environmental compliance.
Maximum operating temperature up to 110°C for high thermal tolerance.

Product Description

TDK B32529C0102K289 Polyester Capacitor (PET) 1 nF 63V AC/DC Through Hole 2-Pin is a metallized polyester film capacitor designed for reliable blocking, coupling, decoupling, bypassing, and radio frequency interference (RFI) reduction in automotive and industrial electronics.

This capacitor features stacked-film technology with polyethylene terephthalate dielectric material, enhancing stability and pulse strength. It is housed in a robust plastic case with epoxy sealing to protect against environmental factors.

The capacitor is mounted via through-hole with a 5 mm lead pitch and features parallel wire lead terminals made from lead-free tinned materials, complying with RoHS directives.

It conforms to AEC-Q200 Rev D automotive standards ensuring suitability for automotive-grade applications requiring high contact reliability and high pulse strength. Rated for 63 volts AC and DC, it operates safely up to 110°C.

Key dimensions include a length of 7.3 mm, height of 6.5 mm, width of 2.5 mm, and a lead diameter of 0.5 mm, making it compatible with standard PCB assembly processes. It complies with UL safety and environmental certifications.

Capacitance of 1 nanofarad. Rated AC and DC voltage of 63 volts. Automotive AEC-Q200 compliant. Through hole mount with 5 mm lead pitch and 2 pins. Maximum operating temperature 110°C. Metallized polyester film with epoxy sealed plastic case.

Lead-free tinned copper parallel wire leads. UL and RoHS certified. Compact dimensions for PCB integration. High pulse strength and contact reliability.

This capacitor is suitable for industrial, automotive, and electronic manufacturing applications where reliable Film Capacitors are required for signal conditioning and noise suppression.

Explore more capacitors and film capacitor series at EnvMart for your design and production needs.
