Wurth Elektronik Wirewound Surface Mount Inductor WE-GF Series 1812 Package 47 μH ±10% 140 mA 5Ω Max DC Resistance 744766147
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 3.2mm |
| Length | 4.5mm |
| Depth | 3.2mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Standards/Approvals | RoHS, REACH |
| Package/Case | 1812 |
| Maximum DC Current | 140mA |
| Pin Count | 2 |
| Maximum DC Resistance | 5Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 10MHz |
| Minimum Quality Factor | 50 |
| Inductor Construction | Wirewound |
Key Features
- The inductor has a maximum DC current rating of 140 mA.
- Maximum DC resistance is 5 ohms ensuring low power loss.
- Operates within a temperature range from -40°C to 105°C.
- Constructed with a ferrite core and wirewound design to ensure high quality and performance.
- Features a tolerance of ±10% inductance and a minimum quality factor of 50.
- Termination style is surface mount suitable for PCB assembly with tape and reel packaging.
- Non-shielded construction optimized for HF amplifier and LC filter applications.
- Maximum self-resonant frequency is 10 MHz, ideal for high frequency circuits.
Product Description
Wurth Elektronik 744766147 is a wirewound surface mount inductor from the WE-GF series, designed for high frequency applications such as HF amplifiers, oscillators, transponders, LC filter circuits, and adapter networks.
This unshielded inductor features a ferrite core construction with a 47 μH inductance value and an inductance tolerance of ±10%. It supports a maximum DC current of 140 mA and has a maximum DC resistance of 5 ohms to minimize power losses.
The inductor package size is 1812 (4.5 mm length, 3.2 mm height and depth), and it is designed for surface mount technology (SMT) with tape and reel packaging for automated assembly processes.
Its operating temperature range extends from -40°C to 105°C, making it suitable for a variety of industrial and electronic applications operating under diverse temperature conditions. The component offers a minimum quality factor of 50, ensuring effective performance in RF and high frequency circuits.
This product complies with environmental regulations including RoHS and REACH, ensuring they meet modern sustainability standards. The inductor is specialized for use in high frequency amplifier circuits and oscillator applications.
Its wirewound construction and ferrite core provide stable inductance characteristics. Suitable for use in transponders, tuner circuits, and LC filters within communication and electronic devices. Offers low DC resistance to improve circuit efficiency.
Packaged for surface mounting, facilitating automated PCB assembly. Robust specifications allow use in industrial, telecommunications, and consumer electronics sectors. Explore more Surface Mount Inductors and related electronic components through EnvMart's extensive catalog for your project and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductor has an inductance value of 47 μH with a tolerance of ±10%.
It supports a maximum DC current of 140 mA, ensuring efficient operation in various applications.
The maximum DC resistance is 5 ohms, which helps minimize power loss during operation.
The operating temperature range extends from -40°C to 105°C, making it suitable for diverse environments.
The maximum self-resonant frequency is 10 MHz, making it suitable for high frequency circuits.
It features a ferrite core construction, which contributes to its performance in high frequency applications.
The inductor has dimensions of 4.5 mm in length, 3.2 mm in height, and 3.2 mm in depth, packaged in a 1812 size.
This model uses a surface mount termination style, designed for automated PCB assembly processes.
It is specialized for use in high frequency amplifier circuits, oscillators, transponders, and LC filter applications.
The inductor has a minimum quality factor of 50, ensuring effective performance in RF circuits.
It complies with RoHS and REACH environmental regulations, ensuring it meets modern sustainability standards.
It is packaged in tape and reel format, facilitating automated assembly in PCB manufacturing.
