Renesas Electronics Line Transceiver, 3 State, Inverting, 16-Pin SOIC, CMOS Logic, 5V Supply, 15mA Supply HIN202EIBNZ

Renesas Electronics HIN202EIBNZ is a high-performance line transceiver designed for reliable RS-232E and V.28 compatible communication interfaces, especially suited for electronic systems requiring efficient signal transmission without the need for +/-12V supplies.

This device belongs to the CMOS logic family and integrates a single +5V power supply with onboard voltage doubler and inverter circuits, contributing to its low power consumption characteristic.The transceiver supports inverting output polarity and 3-state output capability which enables effective line control in multi-device networks. It is housed in a surface mount 16-pin SOIC package with compact dimensions allowing for versatile PCB integration and saving board real estate.

Operating reliably over a wide temperature range from -40°C to 85°C, the HIN202EIBNZ meets the demands of industrial, commercial, and laboratory electronic applications. Its maximum propagation delay time of 10 microseconds at CL ensures timely signal processing, while the 15mA supply current affirms energy efficiency.

This line transceiver is optimal for use in communication equipment, instrumentation, data acquisition systems, and other electronic devices requiring robust and adaptable interface solutions.

Single +5V power supply operation. Onboard voltage doubler and inverter circuits. CMOS logic family for low power and high noise immunity. Supports TTL and CMOS input levels with 3-state outputs. Compact 16-pin SOIC package with 10 mm by 6.2 mm footprint.

Operational temperature range from -40°C to 85°C. Maximum propagation delay time of 10μs at CL. Typical supply current of 15mA. Inverting output polarity. Reliable interface suited for RS-232E and V.28 compliant systems.
