Wurth Elektronik WR-PHD Series Bottom Entry PCB Socket 32-Contact, 2 Row, 2.54 mm Pitch 61303225721

Wurth Elektronik 61303225721 is a high-quality WR-PHD Series bottom entry PCB socket designed with 32 contacts arranged in 2 rows and a standardized 2.54 mm pitch. This socket is engineered for secure and efficient connections in electronic component assemblies.

The socket housing is made from Nylon 9T, which provides excellent insulation properties and meets UL94 V-0 flammability standards, ensuring safety in demanding industrial and electronic environments. It supports operating voltages up to 250V and currents of 3A, making it suitable for numerous electronic applications, including industrial, HVAC, manufacturing, and laboratory equipment.

Its contacts are fabricated from copper alloy with gold plating, which enhances electrical conductivity and provides corrosion resistance for long-lasting reliability. The contact gender is female, and the socket is designed for bottom entry PCB mounting, simplifying installation onto printed circuit boards.

With an operating temperature range from -40°C to 105°C, this product is versatile for use in varying thermal conditions often encountered in industrial and commercial applications. The socket's durability supports up to 25 mating cycles, ensuring longevity in repeated connect-disconnect scenarios.

This component complies with important industry standards such as RoHS, UL, and REACH, highlighting its environmental and safety credentials. Originating from Taiwan, Province Of China, this product embodies the quality and precision expected from Wurth Elektronik components.

Features a 2.54 mm pitch ensuring standard spacing for electronic assemblies. Constructed with a durable Nylon 9T housing material offering high insulation and fire resistance. Capable of withstanding voltages up to 250V and currents up to 3A, suitable for various electronic applications.

Designed to operate in extreme temperatures ranging from -40°C to 105°C, ensuring versatility in challenging environments. Employs copper alloy contacts with gold plating for enhanced conductivity and corrosion resistance.

Bottom entry orientation facilitates easy PCB mounting and integration. Compliant with RoHS, UL, and REACH standards, ensuring safety and environmental compliance. Durability rated for 25 mating cycles to guarantee reliable mechanical performance.

This PCB socket is ideal for industrial, laboratory, and manufacturing electronics where reliable connections and durability are critical. It fits various applications in low- to mid-power electronic devices and systems. Browse more options in the Electronics Components section at EnvMart for compatible connectors and sockets.
