Vishay Uni-Directional TVS Diode 600 W, 2-Pin DO-221 SMA6F28A-M3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1mm |
| Length | 4.35mm |
| Model | SMA6F28A-M3/H |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-221 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 45.5V |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 31.1V |
| Maximum Reverse Stand-off Voltage Vwm | 28V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 68A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- The diode features a minimum breakdown voltage of 31.1 V and a maximum reverse stand-off voltage of 28 V.
- It supports a peak pulse current of up to 68 A, providing excellent clamping capabilities.
- Operating temperature ranges from -55°C to 175°C ensuring reliability in diverse conditions.
- Compact dimensions of 4.35 mm length, 2.7 mm width, and 1 mm height enable low-profile automated PCB placement.
- Uni-directional polarity protects circuits from voltage transients caused by inductive load switching and lightning.
- The device meets MSL level 1 per J-STD-020, with LF max peak temperature of 260°C for soldering.
- Its low leakage current of 1 μA ensures minimal power loss during normal operation.
- Suitable for consumer electronics, computers, industrial automation, and telecommunication equipment.
Product Description
Vishay SMA6F28A-M3/H Uni-Directional TVS Diode is a robust transient voltage suppressor delivering 600 W peak pulse power designed for protecting sensitive electronic devices against transient voltage spikes. It incorporates a 2-pin DO-221 package type with a compact form factor suitable for automated PCB assembly.
Featuring a minimum breakdown voltage of 31.1 V and a reverse stand-off voltage of 28 V, this diode effectively clamps voltage peaks up to 45.5 V, preventing damage during electrical surges such as those caused by inductive load switching and lightning strikes.
The device supports a maximum peak pulse current of 68 A and is optimized for use in single-element, uni-directional configurations. Its operating temperature range from -55°C to 175°C supports durability under harsh industrial and commercial environments.
With a low profile height of approximately 1 mm and precise dimensions (length 4.35 mm, width 2.7 mm), it fits compact designs and meets Moisture Sensitivity Level 1 per J-STD-020 standards, making it ideal for automated surface-mount production with lead-free soldering requirements.
Low leakage current (1 μA) ensures energy efficiency, while its ESD protection capabilities safeguard integrated circuits, MOSFETs, sensor units, and signal lines in consumer electronics, computing, telecommunications, industrial automation, and manufacturing plants.
Applications include voltage transient suppression in sensitive electronics, industrial control systems, and telecommunication infrastructure to enhance reliability and lifespan of critical equipment.
The diode provides excellent clamping voltage performance ensuring voltage spikes are safely limited. Uni-directional polarity is ideal for circuits requiring single-direction voltage suppression. Compact DO-221 packaging supports space-constrained PCB layouts with automated assembly.
The diode is rated for harsh industrial and commercial use with wide temperature tolerance. Low leakage current and high peak pulse power dissipation offer effective protection with minimal power wastage. Meets Moisture Sensitivity Level 1 (MSL 1) for robust manufacturing and handling processes.
Ideal for diverse industrial, laboratory, telecommunications, and consumer electronics environments. Explore more TVS Diode solutions at EnvMart for advanced transient voltage protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum peak pulse power dissipation of this TVS diode is 600 W.
The minimum breakdown voltage for this model is 31.1 V.
The clamping voltage of this diode is 45.5 V.
The operating temperature range of this model is from -55°C to 175°C.
This diode has dimensions of 4.35 mm in length, 2.7 mm in width, and 1 mm in height.
This diode features a 2-pin configuration.
The maximum reverse stand-off voltage for this diode is 28 V.
The maximum peak pulse current supported by this model is 68 A.
This diode supports surface mounting.
The maximum reverse leakage current for this model is 1 μA.
This diode is uni-directional, providing single-direction voltage suppression.
This diode is suitable for applications in consumer electronics, industrial automation, and telecommunication equipment, providing protection against voltage transients.
