Molex KK Female Connector Housing 5.08 mm Pitch 5 Way 1 Row Straight 10-01-1054

Molex 10-01-1054 KK Female Connector Housing is a high-quality electronic component designed for wire-to-board connections in industrial and electronic assemblies. This connector housing features a 5.08 mm pitch with 5 female contacts arranged in a single row for straight cable mounting. Manufactured using natural UL94V-2 nylon, it offers enhanced fire resistance and durability, making it suitable for demanding applications.

The connector housing is compatible with KK series crimp terminals including KK 2478, KK 2578, and KK 2878, which accommodate wire gauges from 18 to 26 AWG. It mates seamlessly with the KK 3003 PCB header connectors, enabling efficient and economical configuration of electronic connections with improved creepage and clearance distances compared to 3.96 mm pitch connectors.

With a precise length of 25.4 mm and width of 6 mm, the compact design ensures space efficiency in electronic boards and systems. The straight orientation facilitates straightforward cable routing and connector assembly. This component is part of the Molex KK 3001 series known for consistent performance and reliability in various electrical and electronic applications.

Approved by CSA under certifications E29179 and LR19980, the connector housing meets industrial safety standards, ensuring dependable operation in commercial, industrial, and manufacturing settings. Its nylon housing material provides excellent insulation and mechanical strength, suited for high-reliability applications.

Typical use cases include applications in industrial automation, consumer electronics, instrumentation, HVAC controls, and telecommunications equipment where secure and precise electrical connections are critical.

Manufactured from natural UL94V-2 nylon ensuring fire retardance. Compatible with KK 2478, KK 2578, and KK 2878 series crimp terminals supporting 18-26 AWG wires. Designed for wire to board connectivity with economical and simple assembly.

Provides greater creepage and clearance distance compared to smaller pitch connectors. Features a length of 25.4 mm and width of 6 mm suitable for compact electronic assemblies. Supports applications requiring reliable female connector interface with straight orientation.

Part of the Molex KK 3001 series, compatible with KK 3003 PCB header connectors. CSA approved under E29179 and LR19980 standards. Ideal for electronics, industrial, and manufacturing applications where precise connector housing is needed.
