Samtec PET Series Vertical Through Hole PCB Header 4 Contacts 6.35 mm Pitch 1 Row Shrouded PET-04-01-T-VT

Samtec PET-04-01-T-VT is a high-quality vertical through hole PCB header designed to provide secure and reliable board-to-board connections. This component features a 4-contact configuration spaced at a 6.35 mm pitch in a single row arrangement, making it suitable for compact electronic assemblies.

Manufactured with a liquid crystal polymer housing, the header ensures high mechanical strength and excellent resistance to environmental stress. The contacts are crafted from copper alloy and plated with gold over tin, delivering superior conductivity and protection against corrosion, essential for long-term industrial and commercial use.

Rated for a maximum current of 58.7 amperes and voltage of 725 volts, this header supports demanding electrical requirements typical in power electronics and automation equipment. The shrouded design enhances connector mating alignment and retention, reducing risks of incorrect insertion and improving system reliability.

With a temperature operating range spanning from -55°C to 125°C, this PCB header performs reliably in harsh environmental conditions such as industrial controls, telecommunications, and automotive electronics. The solder termination type ensures a durable connection between the header and the printed circuit board, suitable for through hole mounting applications in vertical orientation.

This product is ideal for use in electronic systems requiring robust power transmission and secure signal interfacing, including manufacturing equipment, industrial machinery, HVAC controls, and laboratory instrumentation.

The header features a single row design with shrouded housing for secure mating. Constructed with liquid crystal polymer housing for durability and high performance. Copper alloy contacts are plated with gold over tin for excellent conductivity and corrosion resistance.

Supports a maximum current rating of 58.7 A and voltage rating of 725 V. Designed for through hole mounting in vertical orientation to fit various PCB layouts. Operates in a wide temperature range from -55°C to 125°C for versatile industrial applications.

Termination is by soldering, providing robust mechanical and electrical connections. Ideal for electronic equipment requiring high power and reliable PCB interfacing. Explore more products like the Samtec PET series vertical PCB Headers on EnvMart for quality components in electronics manufacturing and system integration.
