Vishay Shielded Surface Mount Inductor 820 nH ±20% 13.8 A Idc 2225 Package IHLE2525
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 3.23mm |
| Length | 7.21mm |
| Model | IHLE2525 |
| Depth | 3.23mm |
| Series | IHLE2525 |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Inductance | 820nH |
| Standards/Approvals | RoHS |
| Package/Case | 2225 |
| Maximum DC Current | 13.8A |
| Maximum DC Resistance | 7.22mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 68.6MHz |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Shielded inductor with integrated E-field shielding for EMI reduction.
- Inductance value of 820 nH with ±20% tolerance.
- Maximum DC current rating of 13.8 A for high current applications.
- Package dimensions approximately 7.21 mm length, 3.23 mm height, and 3.23 mm depth.
- High maximum operating temperature up to 155 °C suitable for harsh environments.
- Compliant with automotive standard AEC-Q200 for reliability.
- RoHS compliant and molded construction ensuring quality and safety.
- Surface mount termination style for compact PCB assembly.
Product Description
Vishay IHLE2525 shielded surface mount inductor offers high current capability and reliable performance for electronic circuits.
This 2225 package inductor features a nominal inductance of 820 nH with ±20% tolerance and integrated E-field shielding to minimize electromagnetic interference, making it ideal for EMI-sensitive applications.
It supports a maximum DC current of 13.8 A and operates at high temperatures up to 155 °C, complying with rigorous automotive standard AEC-Q200, ensuring robustness in automotive and industrial environments.
The inductor has low DC resistance of 7.22 mΩ to reduce power losses, and a maximum self-resonant frequency of 68.6 MHz, making it suitable for DC/DC converters, filter inductors, and other high-frequency energy storage applications.
Molded for durability and surface mount termination enables easy automated PCB assembly. The Vishay IHLE2525 series is designed for applications requiring high current, compact size, and excellent EMI suppression.
Shielded inductor with integrated E-field shielding for EMI reduction. Inductance of 820 nH with ±20% tolerance. Supports maximum DC current of 13.8 A. Compact 2225 surface mount package dimensions: 7.21 mm length, 3.23 mm height, 3.23 mm depth.
Wide operating temperature range from -55 °C to 155 °C. Complies with automotive AEC-Q200 standard. RoHS compliant with molded construction. Low DC resistance of 7.22 mΩ for energy-efficient operation. Maximum self-resonant frequency of 68.6 MHz for high-frequency applications.
This Vishay Surface Mount Inductor is suitable for industrial electronics, automotive circuits, power supplies, telecommunications, and other commercial applications demanding compact, reliable, and EMI-protected inductors.
Browse EnvMart's wide range of high-quality Vishay inductors and electronic components for your engineering and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 820 nH with a tolerance of ±20%.
It supports a maximum DC current of 13.8 A, making it suitable for high current applications.
The package dimensions are approximately 7.21 mm in length, 3.23 mm in height, and 3.23 mm in depth.
The maximum operating temperature is up to 155 °C, allowing it to function in harsh environments.
Yes, it complies with the automotive standard AEC-Q200 for reliability in automotive applications.
The maximum self-resonant frequency is 68.6 MHz, which is suitable for high-frequency applications.
It features a shielded construction with integrated E-field shielding to reduce electromagnetic interference.
The maximum DC resistance is 7.22 mΩ, which helps to minimize power losses.
This model has a surface mount termination style, facilitating compact PCB assembly.
It can operate within a temperature range from -55 °C to 155 °C.
It is suitable for industrial electronics, automotive circuits, power supplies, and telecommunications, particularly in EMI-sensitive applications.
The country of origin for this inductor is China.
