Samtec TFM Series Horizontal Through Hole PCB Header, 50 Contacts, 1.27 mm Pitch, 2 Row, Shrouded TFM-125-02-S-D-LC-P-TR

The Samtec TFM-125-02-S-D-LC-P-TR is a high-performance horizontal through hole PCB header designed for board-to-board applications requiring reliable and efficient electrical connections. This model offers 50 gold-plated male contacts arranged in two rows with a pitch of 1.27 mm, making it suited for precise, compact layouts.

Its housing is manufactured from liquid crystal polymer, providing excellent mechanical strength and excellent resistance to temperature extremes, validated to operate between -55°C and 125°C. The contact material consists of phosphor bronze with selective gold plating on the contact area and matte tin on the tail to ensure optimal conductivity and durability.

This PCB Header supports a current rating of 3.2 A and voltage rating of 250 V, meeting many industrial, commercial, and laboratory requirements. The shrouded design with a locking clip provides secure mating and protection against incorrect connector insertion, enhancing operational reliability.

The solder termination and through hole mount type make it compatible with standard PCB soldering techniques, facilitating robust mechanical and electrical joints. Supplied on tape and reel packaging, this component supports automated pick and place assembly, improving production efficiency.

Ideal for industrial electronics manufacturing, electronic instrumentation, telecommunications equipment, automotive electronics, and other precision electronic assemblies requiring dependable board-to-board interconnects.

Designed for board-to-board connector systems ensuring reliable electrical connections. Constructed with phosphor bronze contacts plated selectively with 0.000762 mm gold for optimal conductivity. Housing made from durable liquid crystal polymer for high temperature tolerance and mechanical stability.

Supports a current rating of 3.2 A and a voltage of 250 V for robust electrical performance. Operates safely within a temperature range from -55°C to 125°C. Features solder termination type suitable for through hole mounting on PCBs.

Shrouded connector with locking clip enhances mating security and prevents incorrect insertion. Available on tape and reel packaging to facilitate automated assembly processes.
