Samtec MMS Series Straight Surface PCB Socket, 3-Contact, 1 Row, 2 mm Pitch Through Hole MMS-103-02-L-SH-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.9A |
| Model | MMS-103-02-L-SH-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | MMS |
| Termination Type | Through Hole |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Connector System | Board-to-Board |
Key Features
- Constructed with phosphor bronze contacts ensuring excellent conductivity.
- Housing made of liquid crystal polymer offering durability and thermal resistance.
- Termination type is through hole with surface mount system for board-to-board connection.
- Operates between -55°C and 125°C to withstand diverse environmental conditions.
- Supports a maximum current of 3.9 A suitable for various electronic applications.
- Designed as a single horizontal row socket strip with matte tin tails for secure soldering.
- Complies with RoHS standards ensuring environmental compliance.
- Available in tape and reel packaging for automated assembly processes.
Product Description
Samtec MMS-103-02-L-SH-TR is a high-quality straight surface PCB socket engineered for precise board-to-board connections. Featuring 3 contacts arranged in a single row with a 2 mm pitch, it is mounted through hole with a surface mount orientation to ensure robust electrical and mechanical integrity. The contacts are made from phosphor bronze and plated with a thin selective gold layer, providing excellent conductivity and resistance to corrosion.
The socket housing is fabricated from liquid crystal polymer, which offers superior durability and performance under thermal stress. It is rated to operate reliably in harsh environments ranging from -55°C to 125°C, making it suitable for a wide range of industrial, manufacturing, and electronics applications.
Designed as part of the MMS series, this socket supports a current rating of 3.9 A and features matte tin tails to facilitate high-quality solder joints. The product is RoHS compliant, ensuring that it meets strict environmental and safety standards.
The socket is supplied with tape and reel packaging, optimized for automated manufacturing systems, making it ideal for efficient assembly in commercial and industrial production lines. Its compact and straight design allows seamless integration into PCBs requiring reliable and long-lasting connectivity solutions.
Constructed with phosphor bronze contacts for durability. Gold plating on contact area for corrosion resistance. Liquid crystal polymer housing ensures thermal stability. Rated for operation between -55°C and 125°C. Current rating of 3.9 A suitable for diverse applications.
Through hole termination with surface mount for secure fitting. Single row, 3-contact socket strip for standard pitch PCB designs. RoHS compliant for environmental safety. Packaged in tape and reel for automated assembly processes.
This Samtec MMS series PCB Socket is a vital component in electronics manufacturing, laboratory testing setups, telecommunications, and industrial control equipment. For additional high-performance electronic connectors and components, browse the Electronics & Electricals category on EnvMart and explore other Samtec solutions optimized for your engineering needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 3.9 A, making it suitable for various electronic applications.
It operates reliably between -55°C and 125°C, allowing it to withstand diverse environmental conditions.
The contacts are made from phosphor bronze and are plated with gold for corrosion resistance, while the housing is constructed from liquid crystal polymer for durability.
This unit features a through hole termination type with a surface mount system for secure board-to-board connections.
The pitch size of this socket is 2 mm, designed for standard PCB layouts.
It has 3 contacts arranged in a single horizontal row, suitable for various connection needs.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements.
It utilizes a board-to-board connector system, facilitating reliable connections between PCBs.
The socket is available in tape and reel packaging, optimized for automated assembly processes.
This model has a straight orientation, making it suitable for various PCB designs.
The country of origin for this PCB socket is India.
It is classified as a socket strip, designed for specific applications in electronic assemblies.
