Molex Sabre Series Straight Through Hole PCB Header, 2 Contact(s), 7.49 mm Pitch, 1 Row, Shrouded 43160-2102
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Straight |
| Current | 18A |
| Mount Type | Through Hole |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Brass |
| Series | Sabre |
| Termination Type | Solder |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 7.49mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.81mm |
| Row Pitch | 7.5mm |
Key Features
- Features a high temperature thermoplastic housing for durability.
- Supports a maximum current of 18A and voltage up to 600V.
- Includes male brass contacts plated with tin for reliable connectivity.
- Designed with positive locking casings and audible click to prevent accidental disconnection.
- Compatible with wire-to-board connector system via through hole mounting.
- Operates in temperatures from -40°C up to 75°C for versatile environmental use.
- Tail pin length measures 3.81 mm suitable for PCB insertion.
- Complies with UL E29179 and UL1950; CSA LR19980 standards ensuring quality and safety.
Product Description
Molex 43160-2102 Sabre Series Straight Through Hole PCB Header is engineered for reliable wire-to-board connections in industrial and electronic applications. It is a single-row, 2-contact connector with a 7.49 mm pitch, featuring a shrouded design to enhance protection and prevent misalignment during mating.
This PCB header is built with a high temperature thermoplastic housing that withstands rigorous operating conditions while offering robust mechanical protection. The brass contacts plated with tin ensure stable electrical contact with a maximum current rating of 18A and voltage rating of 600V, enabling use in high current setups.
The connector system uses through-hole mounting with male contacts that are solder terminated. The tail pin length of 3.81 mm ensures solid insertion into PCBs. The shrouded housing includes positive locking with an audible click mechanism, guaranteeing secure connections and reducing downtime due to disconnections.
Operating comfortably in a temperature range from -40°C to 75°C, this component suits a broad spectrum of applications such as automation equipment, power supplies, industrial controls, and other electronic manufacturing scenarios.
Designed to comply with UL E29179 and UL1950 plus CSA LR19980 standards, the Molex Sabre Series PCB header offers certified performance and safety assurance. The product is ideal for use in industrial, manufacturing, HVAC, and laboratory environments requiring robust wire-to-board connectivity.
High temperature thermoplastic housing improves durability and heat resistance. Male brass contacts with tin plating provide reliable electrical contact. Positive locking casings with audible click prevent accidental disconnection.
Through-hole mount design facilitates secure PCB integration. Wide operating temperature range from -40°C to 75°C for various environments. Compatible with 14 to 18 AWG wire for flexible wiring options. Meets UL and CSA standards for quality and safety.
Shrouded design ensures correct mating orientation and enhanced protection. Choose the Molex Sabre Series 43160-2102 for dependable high current PCB connector solutions. Browse our Electronics Components category for more related products at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum current of 18A and a voltage rating of 600V, making it suitable for high current applications.
It uses through-hole mounting, which facilitates secure integration into PCBs.
The pitch size of the contacts is 7.49 mm, which is essential for proper alignment and connection.
The housing is made from high temperature thermoplastic, while the contacts are brass plated with tin for reliable connectivity.
It operates within a temperature range of -40°C to 75°C, allowing for versatile environmental use.
The tail pin length measures 3.81 mm, which is suitable for PCB insertion.
Yes, it features positive locking casings with an audible click to prevent accidental disconnection.
It complies with UL E29179 and UL1950, as well as CSA LR19980 standards, ensuring quality and safety.
This model has 2 contacts, designed for reliable wire-to-board connections.
The orientation of this connector is straight, which is typical for through-hole mounting applications.
It is compatible with a wire-to-board connector system, enhancing its versatility in various applications.
This PCB header is suitable for applications in automation equipment, power supplies, industrial controls, and electronic manufacturing.
