Samtec TFC Series Vertical Surface PCB Header 20 Contacts 1.27 mm Pitch 2 Row Shrouded TFC-110-02-F-D-A-K-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 3.1A |
| Model | TFC-110-02-F-D-A-K-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TFC |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- Designed with liquid crystal polymer housing for durability and heat resistance.
- Phosphor bronze contacts plated with gold for superior conductivity and corrosion resistance.
- Supports operating temperatures from -55°C to 125°C for industrial use.
- Rated for 3.1A current and 350V voltage ensuring robust electrical performance.
- Surface mount type with vertical orientation and dual row for compact PCB integration.
- Shrouded design provides alignment and protection for safer mating.
- Includes polyimide film pick and place pad for automated assembly compatibility.
- Packaged in tape and reel format for efficient manufacturing processes.
Product Description
Samtec TFC-110-02-F-D-A-K-TR is a vertical surface mount PCB header from the TFC Series, featuring 20 male contacts arranged in 2 rows with a 1.27 mm pitch. It is constructed with a robust liquid crystal polymer housing and phosphor bronze contact material plated in gold to ensure excellent electrical conductivity and durability.
This shrouded header is well suited for board-to-board connections, delivering a current rating of 3.1A and voltage withstand of up to 350V. It operates reliably within a wide temperature range of -55°C to 125°C, making it ideal for demanding industrial, telecommunications, and electronic assembly applications.
The product includes alignment pins and a polyimide film pick and place pad, making it compatible with automated surface mount assembly lines. Its tape and reel packaging further enable streamlined manufacturing and handling.
Commonly used in electronics components, the Samtec TFC series PCB headers provide cost-effective and reliable solutions for high-performance electronic circuits and systems integration.
Designed with liquid crystal polymer housing for durability and heat resistance. Phosphor bronze contacts plated with gold for superior conductivity and corrosion resistance. Supports operating temperatures from -55°C to 125°C for industrial use.
Rated for 3.1A current and 350V voltage ensuring robust electrical performance. Surface mount type with vertical orientation and dual row for compact PCB integration. Shrouded design provides alignment and protection for safer mating.
Includes polyimide film pick and place pad for automated assembly compatibility. Packaged in tape and reel format for efficient manufacturing processes. This product is classified under PCB Headers within Electronics & Electricals, suited for use in industrial, manufacturing, electronics assembly, and telecommunications sectors.
Explore more premium electronic components and connectors in the PCB Headers category at EnvMart to meet all your high-precision PCB assembly requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3.1A, ensuring robust electrical performance for various applications.
It has a voltage withstand capability of up to 350V, making it suitable for high-voltage applications.
The contacts are arranged with a pitch of 1.27 mm, allowing for compact PCB integration.
It features a liquid crystal polymer housing and phosphor bronze contacts plated with gold for enhanced conductivity and corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C, suitable for industrial environments.
This model includes 20 male contacts arranged in 2 rows, facilitating board-to-board connections.
It is designed for surface mounting, providing a vertical orientation for space-efficient PCB layouts.
Yes, it includes a polyimide film pick and place pad, making it compatible with automated assembly processes.
It features a shrouded design that provides alignment and protection for safer mating during connections.
The termination type for this model is solder, which is standard for PCB headers.
The country of origin for this product is India.
It is commonly used in industrial, telecommunications, and electronic assembly applications due to its robust specifications.
