Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header, 2 Contacts, 4.2 mm Pitch, Shrouded, 9A, 600V MPC4
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 600V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 9A |
| Model | MPC4 |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-MPC4 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 4.2mm |
| Standards/Approvals | RoHS, UL E323964 |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 19.6mm |
Key Features
- The header supports a current rating of 9 amperes.
- It features a right angle orientation suitable for compact PCB layouts.
- Contacts are made of copper alloy and plated with tin for corrosion resistance.
- The housing is constructed from durable polyamide (PA66) material.
- Designed with one row of pins and shrouded connectors for enhanced safety.
- Mount type is through hole, facilitating robust mechanical and electrical connection.
- Capable of withstanding operating temperatures from -40°C to 105°C.
- Tail pin length is 19.6 mm to ensure secure soldering connections.
Product Description
Wurth Elektronik MPC4 Series right angle through hole PCB header offers a high-quality wire-to-board connection solution with 2 male contacts and a 4.2 mm pitch. Constructed with a polyamide housing and copper alloy contacts plated with tin, this header is designed for durability and reliable electrical performance in industrial and electronic assembly applications.
The single-row, shrouded connector system ensures safe and easy mating, preventing accidental damage and misalignment. The right angle orientation optimizes PCB layout flexibility, making it suitable for dense electronic circuits.
This header is rated for 9A current and 600V voltage, supports operating temperatures ranging from -40°C to 105°C, making it ideal for use in industrial electronics, manufacturing equipment, control systems, and power supply assemblies.
Compliance with RoHS and UL standards (UL E323964) guarantees safe and environmentally friendly usage. The header supports a current rating of 9 amperes. Right angle orientation enables compact PCB assembly. Copper alloy contacts with tin plating resist corrosion.
Polyamide housing provides mechanical strength and insulation. Shrouded design enhances connector protection and safety. Through hole mount type ensures robust installation. Wide temperature operating range from -40°C to 105°C.
Voltage rating of 600 volts supports diverse electronic applications. Tail pin length of 19.6 mm ensures solid solder joints. Meets RoHS and UL E323964 regulatory standards. This PCB header is made in Taiwan, Province Of China.
Choose this Wurth Elektronik WR-MPC4 Series PCB Header for reliable, high-current electronic connections in demanding industrial, laboratory, manufacturing, and electronic assembly environments. Explore EnvMart's extensive range of PCB connectors and headers to find compatible components that meet your system design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 9 amperes.
The voltage rating for this model is 600 volts.
The pitch size of the contacts is 4.2 mm.
The housing is made from polyamide (PA66), and the contacts are copper alloy plated with tin.
The tail pin length is 19.6 mm, ensuring secure soldering connections.
It can operate within a temperature range of -40°C to 105°C.
This model features 2 male contacts.
The mount type for this header is through hole, facilitating robust connections.
Yes, it complies with RoHS and UL standards (UL E323964).
This header has a right angle orientation, suitable for compact PCB layouts.
It utilizes a wire-to-board connector system, designed for easy mating and enhanced safety.
This PCB header is made in Taiwan, Province Of China.
