Samtec FTS Series Vertical Surface Pin Header, 1.27 mm Pitch, 10 Contacts, 2 Row, Unshrouded, Phosphor FTS-105-01-L-DV-TR

Samtec FTS-105-01-L-DV-TR is a high-quality vertical surface mount pin header designed for efficient and reliable electrical connections in electronics manufacturing. This product features 10 male contacts arranged in 2 rows with a 1.27 mm pitch, suitable for compact PCB layouts in industrial and commercial applications.

The pin header uses phosphor bronze contact material plated with gold or tin over nickel to provide excellent conductivity and corrosion resistance. The housing is made from liquid crystal polymer, offering robustness and thermal stability for demanding environments.

Rated to carry up to 3.4 A current and operating reliably between -55°C and 125°C, this connector suits a variety of environments including telecommunications equipment and embedded systems requiring durable board-to-board or board-to-cable connections.

Its unshrouded design allows for versatile connectivity options during assembly or maintenance. The surface mount termination facilitates quick soldering on PCBs, making it suitable for high volume production.

Applications include telecommunications infrastructure, embedded system interfaces, and general electronic device interconnections requiring precise and compact connector solutions.

The pin header features an unshrouded, male contact design for flexible connectivity. Contacts are made from phosphor bronze with gold or tin plating over nickel to ensure durability and conductivity. The housing is constructed from liquid crystal polymer for high thermal and mechanical stability.

Rated for a maximum current of 3.4 A and an operating temperature range from -55°C to 125°C. The vertical orientation optimizes PCB space in compact layouts. Surface mount termination type allows for efficient soldering and assembly.

Ideal for applications in telecommunications, embedded systems, and general electronic circuitry. Meets no specific industry approvals but is designed for reliable and durable electrical connections. Provides a pitch of 1.27 mm and two rows to accommodate complex PCB configurations.

Suitable for both board-to-board and board-to-cable connector systems. Explore more quality electronics components like PCB Pin Headers and connectors at EnvMart to meet your project and manufacturing needs.
