Molex C-Grid III Female Connector Housing 2.54 mm Pitch 15 Way 1 Row Straight 90123-0115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Molex |
| Orientation | Straight |
| Length | 38.1mm |
| Width | 3.43mm |
| Mount Type | Cable |
| Housing Material | PBT |
| Series | C-Grid III |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| For Use With | 797582022 CGrid III Pre-Crimped Lead, 797582023 CGrid III Pre-Crimped Lead, 90119 C-Grid III Crimp Terminal |
| Number of Contacts | 15 |
| Connector Gender | Female |
Key Features
- Constructed from durable PBT housing material for electrical insulation.
- Features a single row with 15 female contacts spaced at 2.54 mm pitch.
- Designed with straight orientation to facilitate cable mounting.
- Compatible with C-Grid III series pre-crimped leads and crimp terminals.
- Non-locking housing with optional polarising pins for secure connector alignment.
- Suitable for use in electronic component assemblies and power connector applications.
- Complies with DIN 41651 and HE13/14 standards for connector systems.
Product Description
Molex 90123-0115 is a precision-engineered C-Grid III female connector housing featuring a 2.54 mm pitch and 15 way, 1 row straight configuration. This connector housing is fabricated from robust PBT material ensuring excellent insulation and mechanical stability in electronic and power connection applications.
The housing length of 38.1 mm and width of 3.43 mm make it suitable for compact PCB or cable mounting designs where reliable electrical contact is critical. Its design accommodates 15 female contacts arranged in a single row with standard 2.54 mm spacing, widely recognized for compatibility in industrial electronics connector systems.
Intended for cable mount use, this non-locking connector housing comes with straight orientation to ease wire routing and assembly. Optional polarising pins are available to prevent mating errors and ensure correct alignment, improving assembly consistency and operational reliability in complex wiring harnesses.
Compatible with Molex C-Grid III pre-crimped leads and crimp terminals, it integrates seamlessly into manufacturing workflows focused on quality and efficiency. The connector adheres to DIN 41651 and HE13/14 standards, confirming its suitability for industrial, laboratory, manufacturing, and electrical power distribution sectors.
Constructed from durable PBT housing material for electrical insulation. Features a single row with 15 female contacts spaced at 2.54 mm pitch. Designed with straight orientation to facilitate cable mounting. Length measures 38.1 mm and width 3.43 mm for compact installation.
Compatible with C-Grid III series pre-crimped leads and crimp terminals. Non-locking housing with optional polarising pins for secure connector alignment. Suitable for use in electronic component assemblies and power connector applications.
Complies with DIN 41651 and HE13/14 standards for connector systems.
This Connector Housing is ideal for electronics manufacturing, power connector assemblies, and applications requiring reliable single-row female connector interfaces. Explore other Molex C-Grid III connectors and related products for comprehensive electrical solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector housing features a 2.54 mm pitch and includes 15 female contacts arranged in a single row.
The housing measures 38.1 mm in length and 3.43 mm in width, making it suitable for compact installations.
The connector housing is constructed from PBT material, which provides electrical insulation and mechanical stability.
Yes, it is compatible with Molex C-Grid III pre-crimped leads such as 797582022 and 797582023, as well as the 90119 C-Grid III crimp terminal.
The connector housing is designed with a straight orientation to facilitate cable mounting and ease wire routing during assembly.
This model features a non-locking housing design, but it includes optional polarising pins to ensure secure connector alignment and prevent mating errors.
It complies with DIN 41651 and HE13/14 standards for connector systems, confirming its suitability for various applications.
This housing supports cable mounting, making it suitable for various electronic component assemblies and power connector applications.
The connector housing features a single row configuration, accommodating 15 female contacts.
It is suitable for use in electronic component assemblies and power connector applications, particularly in industrial and laboratory settings.
The country of origin for this connector housing is India.
The connector gender of this housing is female, designed to accept corresponding male connectors.
