Samtec TSM Series Vertical Surface Pin Header 3 Contacts 2.54 mm Pitch 1 Row Unshrouded TSM-103-01-L-SV-A
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.4A |
| Model | TSM-103-01-L-SV-A |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- Constructed with a black liquid crystal polymer housing ensuring durability.
- Features phosphor bronze contacts plated with gold for reliable conductivity.
- Rated for a current of 5.4 amperes supporting moderate circuit loads.
- Operates effectively within a temperature range from -55°C to 125°C.
- Designed for board-to-board connector systems with vertical orientation.
- Surface mount termination type ensures easy soldering on PCBs.
- Unshrouded contact configuration facilitates versatile mating options.
Product Description
Samtec TSM-103-01-L-SV-A is a vertical surface mount pin header featuring 3 male contacts arranged in one row with a 2.54 mm pitch. The pin header utilizes a robust black liquid crystal polymer housing to ensure mechanical stability and electrical insulation.
The phosphor bronze contacts are plated with gold to provide excellent corrosion resistance and reliable electrical connections. This connector is designed for board-to-board applications where a vertical orientation is required, allowing seamless integration into modern PCB designs.
It supports a maximum current of 5.4 A and can operate reliably in harsh environments ranging from -55°C up to 125°C. With a voltage rating of 475 VAC, it meets typical requirements for industrial and commercial electronic assemblies.
The termination type is solder, simplifying the assembly process onto printed circuit boards with surface mount technology (SMT). Its unshrouded pin configuration provides flexibility for multiple mating connector types or pin header arrangements.
Typical applications include industrial control systems, communication equipment, embedded computing, and general electronic fixtures where reliable board-to-board electrical connectivity is essential.
Constructed with a black liquid crystal polymer housing ensuring durability. Features phosphor bronze contacts plated with gold for reliable conductivity. Rated for a current of 5.4 amperes supporting moderate circuit loads.
Operates effectively within a temperature range from -55°C to 125°C. Designed for board-to-board connector systems with vertical orientation. Surface mount termination type ensures easy soldering on PCBs. Voltage rating of 475 volts AC provides insulation suitability.
Unshrouded contact configuration facilitates versatile mating options.
Samtec connectors offer trusted quality and compatibility for a broad range of electronics manufacturing needs. Explore the PCB Headers category on EnvMart for additional related components and hardware options.
