Samtec PCB Socket SSW Series 2-Contact, 1 Row, 2.54 mm Pitch, Through Hole Solder Termination SSW-102-01-F-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | SSW-102-01-F-S |
| Mount Type | Through Hole |
| Special Features | Standard and low insertion force contacts with standard solder tails |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | SSW |
| Termination | Through-hole, surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Contact System | Tiger Buy™ |
Key Features
- This PCB socket supports board-to-board connector systems for reliable electrical connections.
- It is designed with a liquid crystal polymer housing for high durability and temperature resistance.
- The contacts are bronze, plated with gold, ensuring high conductivity and corrosion resistance.
- Supports continuous current of 4.7 A and voltage up to 655 V, suitable for various electronic applications.
- Operating temperature ranges from -55°C to 125°C, suitable for demanding environments.
- The socket features standard and low insertion force Tiger Buy™ contacts for secure mating with square post terminals.
- It is a through-hole mount type oriented straight for vertical placement on PCBs.
- No industry certifications or approvals are specified for this product.
Product Description
Samtec SSW-102-01-F-S PCB Socket is a high-quality board-to-board connector designed for electronic components and power systems. Featuring a 2-contact, single-row configuration and a 2.54 mm pitch, it provides reliable connectivity in demanding industrial and commercial electronics applications.
Constructed with a liquid crystal polymer housing material, it ensures robust performance against mechanical and thermal stresses, with operational temperature tolerances from -55°C to 125°C. The bronze contact material plated with gold enhances electrical conductivity and corrosion resistance, contributing to superior signal integrity.
This solder tail socket strip includes Tiger Buy™ contacts, offering both standard and low insertion force options, optimized for mating with .025" square post terminals. Its through-hole mounting and straight orientation facilitate secure PCB attachment and efficient assembly.
Designed for currents up to 4.7 A and voltages reaching 655 V, this SSW series socket is ideal for single, double, or triple-row configurations in various industrial, laboratory, and commercial electronics systems.
Board-to-board connector system for reliable electrical paths. Housing material made of liquid crystal polymer for durability. Gold-plated bronze contacts ensure exceptional conductivity. Supports operating temperatures from -55°C to 125°C.
Through-hole solder termination for secure mounting. Tiger Buy™ contacts minimize insertion force stress on terminals. Standard and low force options available for different assembly needs. Suitable for industrial, commercial, and laboratory electronics.
This product is supplied new by Samtec and forms part of the SSW series, which is renowned for cost-effective, high-retention PCB socket solutions. It is ideal for customers seeking consistent performance and durability in their PCB assembly processes.
Explore more PCB Sockets and related components in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous current rating for this socket is 4.7 A.
This PCB socket supports a maximum voltage of 655 V.
The operating temperature range for this model is from -55°C to 125°C.
This socket features through-hole solder termination for secure mounting.
The housing is made from liquid crystal polymer, and the contacts are bronze plated with gold.
This socket has 2 contacts in a single-row configuration.
The pitch size for this model is 2.54 mm.
It features standard and low insertion force contacts optimized for mating with .025" square post terminals.
The orientation of this socket is straight, allowing for vertical placement on PCBs.
Yes, it is suitable for various industrial, commercial, and laboratory electronics applications.
The country of origin for this PCB socket is India.
This model supports a board-to-board connector system for reliable electrical connections.
