Samtec TFM Series Straight Through Hole PCB Header, 4 Contacts, 1 Row, 1.27 mm Pitch, Shrouded, Through TFM-104-01-L-S-WT
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | TFM-104-01-L-S-WT |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TFM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- The header features 4 contact positions in a single row for efficient board-to-board connections.
- Constructed with a liquid crystal polymer housing ensuring robust insulation and mechanical strength.
- Includes gold-plated phosphor bronze contacts for reliable electrical conductivity and corrosion resistance.
- Designed for through-hole mounting and comes shrouded for enhanced protection.
- Rated for a current of 3.2A and a voltage of 250V for quality performance in electronic assemblies.
- Operates reliably within a temperature range from -55°C to 125°C.
- Compatible with solder termination type for secure and durable PCB attachment.
- The header has a shrouded design to prevent accidental contacts and mechanical damage.
Product Description
Samtec TFM-104-01-L-S-WT is a premium quality straight through hole PCB header in the TFM series, designed for board-to-board connector applications where reliability and precision are paramount.
This model features 4 contact positions arranged in a single row with a precise pitch of 1.27 mm (0.050 inches), suitable for compact PCB layouts. Its housing is made of liquid crystal polymer, offering excellent mechanical strength and insulation properties, ideal for diverse industrial electronics and manufacturing applications.
The contact pins are composed of phosphor bronze and plated with gold to ensure superior conductivity and resistance to wear and corrosion, thereby enhancing the longevity of the electrical connections.
This shrouded header is designed for through hole mounting, providing robust mechanical stability on the PCB. It supports a current rating of 3.2A and a voltage rating of 250V, making it suitable for various industrial, laboratory, and commercial electronic uses.
Operating temperature ranges from -55°C to 125°C, allowing for deployment in harsh environments. The termination type is solder, facilitating strong and durable connections on printed circuit boards.
The header has a shrouded design to prevent accidental contacts and mechanical damage. Ideal for high-reliability board-to-board connector systems in electronic assemblies. Ensures ease of soldering and assembly on standard PCB manufacturing lines.
Meets industry standards for electronics connector components without specific formal approvals.
This PCB header is widely used in construction of electronic devices, industrial control systems, telecommunications and computing equipment, offering both versatility and performance.
Explore more PCB connectors and headers in the Samtec range at EnvMart for your advanced electronics requirements.
Explore more products in our Electronic Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3.2A, making it suitable for various electronic applications.
The voltage rating for this PCB header is 250V, which allows it to be used in a wide range of electronic assemblies.
The contacts in this header are arranged with a pitch of 1.27 mm (0.050 inches), suitable for compact PCB layouts.
The housing is made of liquid crystal polymer, and the contact pins are composed of phosphor bronze with gold plating for conductivity and corrosion resistance.
It operates reliably within a temperature range from -55°C to 125°C, allowing for use in harsh environments.
This model features 4 contact positions arranged in a single row, facilitating efficient board-to-board connections.
Yes, this header is specifically designed for through-hole mounting, providing robust mechanical stability on the PCB.
The termination type for this PCB header is solder, facilitating strong and durable connections on printed circuit boards.
The orientation of this model is straight, which is suitable for various board-to-board connector applications.
This header supports a board-to-board connector system, making it versatile for different electronic applications.
Yes, it features a shrouded design to prevent accidental contacts and mechanical damage during operation.
The country of origin for this model is India, reflecting its manufacturing location.
