Samtec ESQ Series Vertical Through Hole PCB Socket 36-Contact 2 Row 2.54 mm Pitch Solder ESQ-118-13-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 515V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.7A |
| Model | ESQ-118-13-G-D |
| Mount Type | Through Hole |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | ESQ |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 36 |
| Connector System | Board-to-Board |
| Contact System | Tiger Buy™ |
Key Features
- Features black glass filled polyester housing for durability.
- Supports current rating of 5.7 amperes for reliable electrical performance.
- Gold plated phosphor bronze contacts ensure excellent conductivity and corrosion resistance.
- Designed for vertical orientation and through-hole mounting on PCBs.
- Operates safely within a voltage of 515 volts and temperature range from -55°C to 125°C.
- Standard pitch of 2.54 mm supports PC/104™ applications with Tiger Buy™ contact system.
- Compatible with single, double and triple row configurations up to 108 pins.
Product Description
Samtec ESQ-118-13-G-D is a vertical through hole PCB socket designed for high-reliability electronic applications requiring secure board-to-board connections. Featuring 36 contacts arranged in two rows with a standard 2.54 mm pitch, it provides robust electrical and mechanical performance suitable for industrial and commercial electronics manufacturing.
The housing is constructed from black glass filled polyester offering excellent strength and electrical insulation. Contacts are made from phosphor bronze with gold plating, ensuring superior conductivity and corrosion resistance under demanding conditions.
This PCB Socket supports a current of 5.7 amperes and voltage rating of 515 volts, making it capable of handling moderate power loads. It is rated for continuous operation from -55°C up to 125°C, suitable for harsh environments and extended temperature ranges common in industrial applications.
The socket terminates via solder for through-hole mounting, oriented vertically to facilitate compact PCB design. The Tiger Buy™ contact system allows for low insertion force and reliable electrical contact performance, ideal for single, double, or triple row usage with up to 108 pins in total.
Durable black glass filled polyester housing. Gold plated phosphor bronze contacts for enhanced reliability. Current rating of 5.7A and voltage rating of 515V. Wide operating temperature range from -55°C to 125°C. Through-hole, vertical orientation for versatile PCB mounting.
Standard 2.54 mm pitch supports PC/104™ standards. Tiger Buy™ contact system for low insertion force and secure connection.
This product is ideal for use in industrial electronics, embedded systems, telecommunications, instrumentation, and other applications requiring reliable PCB interconnect solutions. Samtec ESQ series sockets are engineered to enhance durability and performance in complex electronic assemblies.
Explore related PCB connectors, sockets, and components at EnvMart for complete interconnect solutions.
