Samtec SSW Series Straight Through Hole PCB Socket 14-Contact, 1 Row, 2.54 mm Pitch, Surface Mount SSW-114-02-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | SSW-114-02-T-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Current Rating | 4.7A per pin(2 pins powered) |
| Series | SSW |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Sub Type | Solder Tail |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Max Cycles | 100 with 10μ" (0.25μm) |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 14 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- This PCB socket has a current rating of 4.7A per pin with 2 pins powered.
- It uses phosphor bronze contact material plated with tin for reliable conductivity.
- Housing is made from liquid crystal polymer suitable for high temperature applications.
- The mount type is through hole with a straight orientation for board-to-board connector systems.
- Rated for voltages up to 655V and operating temperatures from -55°C to 105°C.
- Incorporates the Tiger Buy™ contact system ensuring stable electrical connections.
- Supports a maximum of 100 mating cycles with 10μ" (0.25μm) contact plating thickness.
- Designed for industrial and electronic component assembly applications.
Product Description
The Samtec SSW-114-02-T-S is a high-quality straight through hole PCB socket designed for electronic component interconnection. It features 14 contacts arranged in one row with a 2.54 mm pitch and surface mount termination type. Its housing is manufactured from liquid crystal polymer, providing excellent mechanical strength and high temperature resistance, suitable for a wide range of industrial and laboratory uses.
This PCB socket supports a current rating of 4.7A per pin (with 2 pins powered) and can handle voltages up to 655V, making it ideal for board-to-board connector systems requiring reliable performance in demanding environments.
The socket employs phosphor bronze contact material with tin plating to ensure low contact resistance and secure electrical connections. It incorporates the Tiger Buy™ contact system, which enhances durability and contact reliability through 100 mating cycles with a plating thickness of 10 microns (0.25 micrometers).
Operating temperature range from -55°C to 105°C allows this socket to be used in various applications including industrial equipment, communication devices, and consumer electronics manufacturing.
This PCB socket has a current rating of 4.7A per pin with 2 pins powered. It uses phosphor bronze contact material plated with tin for reliable conductivity. Housing is made from liquid crystal polymer suitable for high temperature applications.
The mount type is through hole with a straight orientation for board-to-board connector systems. Rated for voltages up to 655V and operating temperatures from -55°C to 105°C. Incorporates the Tiger Buy™ contact system ensuring stable electrical connections.
Supports a maximum of 100 mating cycles with 10μ" (0.25μm) contact plating thickness. Designed for industrial and electronic component assembly applications.
This product is widely used in electronics manufacturing, laboratory equipment assembly, and industrial control systems. Its robust construction and electrical ratings ensure dependable performance across many sectors.
Explore more from the Samtec SSW Series PCB Sockets at EnvMart for reliable and precise connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating is 4.7A per pin with 2 pins powered.
It is rated for voltages up to 655V.
The operating temperature range is from -55°C to 105°C.
The housing is made from liquid crystal polymer, and the contact material is phosphor bronze plated with tin.
This model features 14 contacts arranged in one row.
The pitch is 2.54 mm.
It supports a maximum of 100 mating cycles with a contact plating thickness of 10μ" (0.25μm).
It uses surface mount termination type.
The mount type is through hole with a straight orientation.
It is designed for industrial and electronic component assembly applications.
It utilizes a board-to-board connector system.
Yes, the housing material is suitable for high temperature applications, rated up to 105°C.
