Samtec SSW Series Straight Through Hole PCB Socket 15-Contact 1 Row 2.54 mm Pitch Solder SSW-115-01-G-S

Samtec SSW-115-01-G-S is a precision-engineered straight through hole PCB socket from the SSW series designed for reliable board-to-board connections in electronic assemblies. This component features a single row with 15 female contacts spaced at a 2.54 mm pitch, optimized for solder termination and through-hole mounting techniques. The housing utilizes advanced liquid crystal polymer material providing excellent mechanical strength and thermal stability across a wide operating temperature range of -55°C to 125°C.

The contact material is phosphor bronze with a gold plating finish, which offers superior conductivity and resistance to corrosion, making it suitable for demanding industrial and laboratory electronic applications. Each contact supports a current rating of 4.7 A while maintaining a voltage rating of up to 655 V to ensure safe and efficient performance.

This PCB socket incorporates standard and low insertion force contacts, promoting easier mating cycles, and extending the service life of connectors. It operates as a board-to-board connector system, making it ideal for compact printed circuit board designs requiring high reliability and durability in power and signal transmission.

Applications for the Samtec SSW-115-01-G-S include industrial machinery, electronic prototyping, telecommunications equipment, and commercial electronics manufacturing. Its robust features make it highly suitable for environments that expose the connectors to thermal cycling, mechanical stresses, and electrical loads.

Features 15 female contacts arranged in a single row with 2.54 mm pitch. Constructed with liquid crystal polymer housing for durability and high performance. Phosphor bronze contacts plated with gold ensure excellent corrosion resistance and conductivity.

Capable of handling a current of up to 4.7 A per contact. Designed for through-hole mounting and solder termination. Voltage rating up to 655 V suitable for various electronic applications. Operating temperature range from -55°C to 125°C for reliability in harsh environments.

Standard and low insertion force contact design minimizes wear and tear during use. Connector system is board-to-board ensuring stable and secure connections. Ideal for industrial, electronic manufacturing, and PCB assembly applications.
