Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 8-Contact, 2 Row, 1.27 mm Pitch, 3A, 500V 62200821821

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 8-Contact, 2 Row, 1.27 mm Pitch, 3A, 500V 62200821821

Name: Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 8-Contact, 2 Row, 1.27 mm Pitch, 3A, 500V 62200821821
Brand: Wurth Elektronik
SKU: 165383
Price: 1.15 USD
Availability: InStock



Category PCB Socket Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	500V
Brand	Wurth Elektronik
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	WR-PHD
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	THT Female Dual Row
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Female
Connector System	Board-to-Board

Key Features

This socket features 8 gold-plated female contacts arranged in 2 rows.
It has a pitch of 1.27 mm, suitable for high-density PCB assembly.
Rated for 3 Amps current and 500 Volts voltage, ensuring robust electrical performance.
The housing is made from flame-retardant Polybutylene Terephthalate (PBT) material with UL94 V-0 rating.
It operates reliably within a temperature range from -40°C up to 105°C.
The contacts are stamped from copper alloy and plated with gold for corrosion resistance and contact reliability.
The mounting type is through hole, providing mechanical stability on the PCB.
This connector system is specifically designed for board-to-board interfacing in electronic equipment.

Product Description

Wurth Elektronik 62200821821 WR-PHD Series Straight Through Hole PCB Socket is a high-quality connector engineered for robust PCB board-to-board applications. It features 8 female gold-plated contacts arranged in a dual row layout with a 1.27 mm pitch, ideal for compact and high-density electronic assemblies.

The socket’s black insulator is molded from Polybutylene Terephthalate (PBT), providing UL94 V-0 flame retardant properties suitable for demanding industrial and commercial electronics environments. Its through-hole mount ensures mechanical stability and reliable solder connections on printed circuit boards.

Electrical ratings include a current capacity of 3 Amps and voltage rating of 500 Volts, making it suitable for medium-power electronic circuits. The contacts, composed of stamped copper alloy plated with gold, provide excellent conductivity and resistance to corrosion, enhancing connection durability.

Operating temperature range spans from -40°C to +105°C, enabling usage in diverse environments including industrial, telecommunications, automotive, and laboratory electronics applications. The straight orientation of the connector facilitates ease of insertion and maintenance.

8 gold-plated female contacts provide reliable electrical connection. Dual row, 1.27 mm pitch design supports compact board layouts. Polybutylene Terephthalate housing with UL94 V-0 flame rating for safety. 3 Amp current and 500 Volt voltage rating for medium power applications.

Through-hole mounting ensures strong mechanical fixation on PCBs. Operating temperature range from -40°C to 105°C supports harsh environments. Board-to-board connector system suitable for diverse industrial uses.

This WR-PHD series PCB Socket is made in China and represents Wurth Elektronik’s commitment to quality in the field of electronic components. Ideal for engineers and manufacturers requiring reliable PCB connectors for electronic assemblies ranging from consumer electronics to industrial automation equipment.

Discover more PCB connectors and components at EnvMart to complete your electronic system requirements with high-quality Wurth Elektronik products.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business
