Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 4-Contact, 1 Row, 2.54 mm Pitch Solder 61300411821
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | THT Female Single Row Straight Socket |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- This through-hole PCB socket features 4 gold-plated copper alloy contacts.
- Mount type is through hole with a straight orientation for easy soldering.
- Constructed with a UL94-V0 rated Polybutylene Terephthalate housing ensuring flame resistance.
- Designed to operate under temperatures from -40°C to 105°C for reliable performance.
- Rated for a current of 3A and voltage up to 500V for versatile electronic applications.
- Single row configuration with a 2.54 mm pitch suits standard PCB layouts.
- Contact gender is female, suitable for mating with pins in board-to-board systems.
- Widely used in industrial, electronic manufacturing, and board assembly applications.
Product Description
Wurth Elektronik 61300411821 WR-PHD Series Straight Through Hole PCB Socket is a precise electronic component designed for reliable board-to-board connectivity. It features 4 gold-plated copper alloy contacts arranged in a single row with 2.54 mm pitch, supporting a current rating of 3A and voltage up to 500V. The PCB Socket is manufactured with a Polybutylene Terephthalate housing material that meets UL94-V0 flammability standards, thereby providing safety in high-temperature environments.
The socket employs a female contact gender with solder termination suited for through-hole mounting techniques, ensuring a durable mechanical and electrical connection. It is engineered for operation in a wide temperature range from -40°C to 105°C, making it ideal for demanding industrial and electronic applications such as control panels, embedded systems, automation modules, and other PCB assemblies.
This reliable connector supports board-to-board communication with a straight orientation facilitating consistent alignment and stability. Its compact footprint with a 2.54 mm pitch and one-row design caters to standard PCB layouts, simplifying integration across various electronic devices.
This socket has 4 gold-plated contacts to ensure optimal conductivity and resistance to corrosion. The Polybutylene Terephthalate housing provides enhanced mechanical stability and flame retardance. Solder termination allows for robust through-hole assembly and excellent mechanical retention.
Rated for continuous operation between -40°C and 105°C, suitable for industrial environments. Current capacity of 3A and voltage rating of 500V enable versatile usage scenarios. The female contact configuration supports multiple applications requiring secure panel connections.
The product is made in Taiwan, Province Of China, adhering to strict manufacturing standards.
Overall, the Wurth Elektronik WR-PHD series socket is a dependable component that ensures electrical integrity and mechanical reliability. It is suitable for electronic manufacturing, industrial automation, telecommunications, and other sectors needing durable PCB interconnect solutions.
Discover a broad range of high-quality PCB connectors and sockets at EnvMart for your electronic assembly requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB socket is 500V, making it suitable for various electronic applications.
This model has a current capacity of 3A, allowing it to handle a range of electronic applications effectively.
The pitch size of this PCB socket is 2.54 mm, which is standard for many PCB layouts.
It utilizes through-hole mounting, which is ideal for creating robust connections on PCBs.
This socket can operate within a temperature range of -40°C to 105°C, suitable for demanding environments.
The housing is constructed from Polybutylene Terephthalate, which meets UL94-V0 flammability standards.
This model features 4 contacts, arranged in a single row for efficient board-to-board connectivity.
The contact gender is female, designed to mate with pins in board-to-board systems.
It employs solder termination, which facilitates a secure and reliable connection when mounted.
This PCB socket is manufactured in Taiwan, adhering to strict manufacturing standards.
It is widely used in industrial, electronic manufacturing, and board assembly applications, including control panels and embedded systems.
The contacts are made from gold-plated copper alloy, ensuring optimal conductivity and corrosion resistance.
