HARWIN M80 Series 16-Contact 2 Row 2 mm Pitch Straight Through Hole PCB Socket M80-8501645
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M80-8501645 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Beryllium Copper Alloy, Brass |
| Series | M80 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket is made of nylon housing for durability and insulation.
- It supports a current rating of 12A and voltage up to 120V.
- The contacts are female and composed of beryllium copper alloy and brass with gold plating for reliable conductivity.
- Mounting is through hole with a straight orientation ensuring secure connections.
- It operates under a temperature range from -55°C to 125°C, suitable for harsh environments.
- The M80 series connectors are designed for high reliability with a four-finger contact clip to resist vibration and shock.
- The socket is compliant with military and British standards including BS9525-F0033 and MIL C 55302.
- It is manufactured in the United Kingdom, ensuring quality assurance.
Product Description
HARWIN M80-8501645 PCB Socket is a high-reliability, 16-contact, 2-row straight through hole connector with 2 mm pitch, designed for board-to-board electronic connections. It supports a rated current of 12A and voltage of up to 120V, making it suitable for demanding industrial and electronic applications.
Constructed with a sturdy nylon housing and female contacts made from beryllium copper alloy and brass, plated in gold, this socket ensures excellent conductivity and durability. Its through-hole mounting and straight orientation facilitate secure and stable connections on printed circuit boards.
The product operates effectively in extreme temperature ranges from -55°C to 125°C, making it dependable in harsh operational environments, including manufacturing, aerospace, and industrial electronics assembly.
The M80 series features a four-finger contact clip design that provides high mating cycle reliability and resistance to vibration, shock, and acceleration, adhering to military and industrial standards such as BS9525-F0033 and MIL C 55302. This socket is manufactured in the United Kingdom with high quality standards.
The socket housing is nylon, ensuring insulation and robustness. It has 16 contacts arranged in 2 rows for compact and efficient connection. The pitch between contacts is 2 mm, aligning with standard PCB layouts. Contact materials and gold plating deliver excellent electrical performance.
Termination type is solder for secure PCB connection. Operating voltage is 120V with 12A current rating suitable for various electronics needs. Temperature range from -55°C to 125°C makes it suitable for extreme operating conditions.
Connector is designed for board-to-board applications with straight orientation.
This PCB socket is ideal for industrial, electronic manufacturing, aerospace, and other applications requiring durable, high-performance connectors. Browse other high-quality HARWIN connectors and PCB Sockets on EnvMart for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 12A and a voltage of up to 120V.
The contacts are made from a beryllium copper alloy and brass, with gold plating for enhanced conductivity.
This socket features through-hole mounting with a straight orientation for secure connections on printed circuit boards.
The pitch between the contacts is 2 mm, which aligns with standard PCB layouts.
This socket has 16 contacts arranged in 2 rows.
The termination type for this model is solder, ensuring a secure connection to the PCB.
It complies with military and British standards including BS9525-F0033 and MIL C 55302.
The contacts are oriented in a straight configuration, facilitating easy installation.
This socket is manufactured in the United Kingdom, ensuring quality assurance.
It is designed for board-to-board connections in industrial, electronic manufacturing, and aerospace applications.
The housing is made of nylon, providing insulation and robustness for the connector.
